GEAR SHIFT SELECTOR DRUM / FORK

GEAR SHIFT SHAFT / LEVER FOR YAMAHA DRAGSTAR 2002

FRAME

SHIFT LEVER ASSY

5EL181200000 5EL181200000

Not available

SPRING, TENSION (4H7)

905060822700 905060822700

4,24 $

Unit Price

STOPPER LEVER ASSY

5EL181400000 5EL181400000

93,98 $

Unit Price

SPRING, TORSION (4H7)

905083253500 905083253500

7,34 $

Unit Price

CIRCLIP

990011060000

990061060000

4,28 $

Unit Price

SPRING, TORSION (4X7)

905082953100 905082953100

4,72 $

Unit Price

WASHER

902011258800 902011258800

7,75 $

Unit Price

COLLAR

90387124F400

903871203300

8,19 $

Unit Price

WASHER

902011258800 902011258800

7,75 $

Unit Price

WASHER PLATE 164185720000

902011216600 902011216600

2,62 $

Unit Price

PIN, DOWEL (4H7)

936085015800 936085015800

5,63 $

Unit Price

SHIFT PEDAL ASSY

5EL181100000 5EL181100000

135,32 $

Unit Price

.GARNITURE, PEDALE DE SELECTEUR GARNITURE, PEDALE DE SELECTEUR

22M181130000 22M181130000

Not available

COVER, DUST

2H9181540000 2H9181540000

13,79 $

Unit Price

WASHER PLATE 278111750000

902011236200 902011236200

5,10 $

Unit Price

CIRCLIP(10Y)

990091240000 990091240000

3,59 $

Unit Price

ARM, SHIFT

5EL181120000 5EL181120000

115,14 $

Unit Price

COVER, DUST

2H9181540000 2H9181540000

13,79 $

Unit Price

BOLT(3DM)

970240602000 970240602000

3,66 $

Unit Price

ROD, SHIFT

4DN181152000 4DN181152000

20,35 $

Unit Price

NUT (2H9)

901700622800 901700622800

3,89 $

Unit Price

NUT(650)

953040670000

953800670000

4,53 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the GEAR SHIFT SHAFT / LEVER of your Yamaha XVS1100 of 2002. Let us know if you have any questions.
