STARTER MOTOR

STARTER CLUTCH FOR YAMAHA XT 1986

TRANSMISSION

2J2-16150-00-00 *

583161500000 583161500000

427,77 $

Unit Price

THRUST PLATE 2

170161640000 170161640000

11,21 $

Unit Price

CLUTCH BOSS

583163710000 583163710000

122,47 $

Unit Price

FRICTION PLATE

5Y1163210000 5Y1163210000

18,60 $

Unit Price

360-16325-10-00 *

360163250000 360163250000

19,85 $

Unit Price

PRESSURE PLATE

498163510000 498163510000

75,57 $

Unit Price

SPRING(583) CLUTCH

905012339100 905012339100

8,91 $

Unit Price

SCREW & WASHER 583

901590601000 901590601000

6,55 $

Unit Price

SPACER (583)

905602515300 905602515300

29,75 $

Unit Price

PIGNON D ENTRAINEMT PRIMAIRE (30T) PIGNON D ENTRAINEMT PRIMAIRE (

583161110000 583161110000

Not available

CLAVETTE, DROITE

902820802100 902820802100

Not available

WASHER, CLUTCH

902081601900 902081601900

3,60 $

Unit Price

90170-16425-00 *

901701618200 901701618200

7,51 $

Unit Price

THRUST PLATE

363161540000 363161540000

12,15 $

Unit Price

SPRING WASHER

214161190000 214161190000

5,70 $

Unit Price

NUT HEX(36311555)

901701808600 901701808600

5,71 $

Unit Price

PUSH ROD

174163560000 174163560000

10,49 $

Unit Price

PUSH ROD

583163570100 583163570100

22,66 $

Unit Price

583-16381-00-00 *

583163820000 583163820000

42,93 $

Unit Price

JOINT

214163890000 214163890000

5,68 $

Unit Price

PIN WITH HOLE

902400600500 902400600500

3,63 $

Unit Price

COTTER PIN

914011001000 914011001000

0,27 $

Unit Price

TORSION SPRING

905081227900 905081227900

4,07 $

Unit Price

BEARING, ROLLER 10

933151172000 933151172000

26,90 $

Unit Price

OIL SEAL (48U)

931021735700 931021735700

14,71 $

Unit Price

90201-18262-00 *

902011732700 902011732700

5,07 $

Unit Price

ADJUSTING SCREW

364163430000 364163430000

6,23 $

Unit Price

NUT, CLUTCH ADJUST

583163440000 583163440000

13,44 $

Unit Price

WASHER, PLATE 3412

902011217200 902011217200

7,13 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the STARTER CLUTCH of your Yamaha XT500 of 1986. Let us know if you have any questions.
