STAND / FOOTREST

STAND / FOOTREST 2 FOR YAMAHA XSR 2023

REAR BRAKE MASTER CYLINDER

Item numbers

BRACKET, ADAPTER 2

B34274A40000 B34274A40000

137,01 $

Unit Price

BOLT

901111006000

901111000600

7,77 $

Unit Price

CLAMP

904650804500 904650804500

9,91 $

Unit Price

BOLT, FLANGE

950220601000 950220601000

1,04 $

Unit Price

REPOSE-PIEDS

1RC274610000 1RC274610000

Not available

PIN, CLEVIS

917010804000

917020804000

3,88 $

Unit Price

PIN, COTTER

914022501500

914902502000

3,93 $

Unit Price

RESSORT, TORSION

9050818X0100 9050818X0100

Not available

COVER, FOOTREST

23P274130000 23P274130000

15,61 $

Unit Price

BOULON

9010908X1300 9010908X1300

Not available

BRACKET 3

1WS274431000 1WS274431000

184,19 $

Unit Price

DAMPER, FOOTREST

36Y274140000 36Y274140000

27,17 $

Unit Price

STOPPER, MAIN STAND

5VX271140000 5VX271140000

2,52 $

Unit Price

PLAQUE 2

B4TF74460000 B4TF74460000

Not available

BOLT, BUTTON HEAD

920140803000 920140803000

2,61 $

Unit Price

PEDAL, BRAKE

BAT272110000 BAT272110000

115,57 $

Unit Price

COVER, SHIFT PEDAL

1WS181130000 1WS181130000

WASHER, WAVE (17W)

902061207400 902061207400

3,94 $

Unit Price

BOLT

4BP274340100

4BP274341100

5,89 $

Unit Price

WASHER, PLATE

902011205100 902011205100

1,97 $

Unit Price

WASHER, PLATE

902010805300 902010805300

4,39 $

Unit Price

SPRING, TENSION

905062300800 905062300800

5,65 $

Unit Price

BOLT, HEXAGON SOCKET HEAD(38V)

901100807100 901100807100

8,56 $

Unit Price

WASHER(1UF)

902090829500 902090829500

7,75 $

Unit Price

COVER 2

B34F74631000 B34F74631000

327,89 $

Unit Price

GROMMET

904801400300 904801400300

3,86 $

Unit Price

COLLAR

903870633500 903870633500

7,83 $

Unit Price

SCREW(4DN)

901490630200 901490630200

6,93 $

Unit Price

RIVET

902690800800 902690800800

2,18 $

Unit Price

REPOSE-PIEDS, ARRIERE 2

BJVF74410000 BJVF74410000

Not available

BRACKET 5

BJVF742L0000 BJVF742L0000

401,02 $

Unit Price

SPRING, COMPRESSION (22N)

905011274300 905011274300

3,98 $

Unit Price

BALL

935010401100 935010401100

0,74 $

Unit Price

WASHER, SPECIAL

5VX274370000 5VX274370000

10,13 $

Unit Price

PIN, WITH HOLE (2G2)

902400806300 902400806300

9,22 $

Unit Price

PIN, COTTER

914012501500

914902502000

3,93 $

Unit Price

BOLT, FLANGE

901050805300 901050805300

7,70 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
