FRAME

FENDER FOR YAMAHA XSR 2023

SIDE COVER

Item numbers

GARDE BOUE AV

B34F151100P4 B34F151100P4

Not available

COLLERETTE 1

B34F15440000 B34F15440000

Not available

BOULON

9011106X2000 9011106X2000

Not available

WASHER, PLATE

902010607200 902010607200

2,67 $

Unit Price

U-NUT, FLANGE

956040620000 956040620000

4,12 $

Unit Price

BRACKET, FENDER

B34F15122000 B34F15122000

420,29 $

Unit Price

BOLT

901110603800 901110603800

5,12 $

Unit Price

BOX, BATTERY 1

B34H212B0000 B34H212B0000

297,39 $

Unit Price

COVER, BATTERY

B34H21290100 B34H21290100

217,02 $

Unit Price

BOLT, HEXAGON SOCK

901110501100 901110501100

5,11 $

Unit Price

DAMPER, PLATE

9052007X0000 9052007X0000

23,69 $

Unit Price

DAMPER 2

1WS216390000 1WS216390000

10,47 $

Unit Price

BOULON

9010906X2200 9010906X2200

Not available

NUT, CROWN

901760600800 901760600800

3,15 $

Unit Price

90338-06181-00 *

903380601800 903380601800

10,81 $

Unit Price

NUT, SPRING(47R)

901830403900 901830403900

9,60 $

Unit Price

GROMMET 2852163900

904801410000 904801410000

2,98 $

Unit Price

GUARD, FLAP

1WS216420100 1WS216420100

7,51 $

Unit Price

RIVET

902690600200 902690600200

4,24 $

Unit Price

BRACKET, LICENSE

B34F16850000 B34F16850000

206,71 $

Unit Price

BOLT, HEXAGON SOCK

901110501100 901110501100

5,11 $

Unit Price

CACHE DE GARDE BOUE AR

B34F165100P4 B34F165100P4

Not available

COLLIER

5D7H25910000 5D7H25910000

Not available

BOLT, HEXAGON SOCK

901110501100 901110501100

5,11 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
