FENDER

SIDE COVER FOR YAMAHA XSR 2022

SWINGARM

Item numbers

GUARD, MUD

B34F16290000 B34F16290000

196,02 $

Unit Price

GROMMET

9048016X0100 9048016X0100

61,36 $

Unit Price

GROMMET

904802548200 904802548200

5,79 $

Unit Price

ECROU

B34F17910000 B34F17910000

Not available

EMBLEME

5P0F17370000 5P0F17370000

Not available

NUT, SPRING

9018305X0400 9018305X0400

14,17 $

Unit Price

BOLT, HEXAGON SOCK

901110609500 901110609500

4,74 $

Unit Price

CLAMP

904611109900 904611109900

2,92 $

Unit Price

TAPPING SCREW, TRU

977074001200 977074001200

0,59 $

Unit Price

COVER, REAR FENDER

B34F163A0000 B34F163A0000

153,30 $

Unit Price

VIS, TETE FRAISEE

9016705X0700 9016705X0700

COVER, SIDE 1

B34F17110000 B34F17110000

121,17 $

Unit Price

GROMMET (4DN)

904800155800 904800155800

12,34 $

Unit Price

MOULURE, COUVERCLE DE PANNEAU

9052003X0000 9052003X0000

Not available

BOLT, HEXAGON SOCK

901110501100 901110501100

5,11 $

Unit Price

NUT, SPRING

9018305X0400 9018305X0400

14,17 $

Unit Price

COVER, SIDE 2

B34F17210000 B34F17210000

121,17 $

Unit Price

GROMMET (4DN)

904800155800 904800155800

12,34 $

Unit Price

MOULURE, COUVERCLE DE PANNEAU

9052003X0000 9052003X0000

Not available

BOLT, HEXAGON SOCK

901110501100 901110501100

5,11 $

Unit Price

NUT, SPRING

9018305X0400 9018305X0400

14,17 $

Unit Price

CACHE LATERALE 3

B34F173100P3 B34F173100P3

Not available

BOLT (3JP)

901110501200 901110501200

1,41 $

Unit Price

CACHE LATERALE 4

B34F174100P3 B34F174100P3

Not available

BOLT (3JP)

901110501200 901110501200

1,41 $

Unit Price

SCOOP, AIR 1

B34F137W0000 B34F137W0000

305,81 $

Unit Price

BOLT, HEXAGON SOCK

901110501100 901110501100

5,11 $

Unit Price

SCOOP, AIR 2

B34F137X0000 B34F137X0000

305,81 $

Unit Price

DAMPER 1

4HM216380000 4HM216380000

0,76 $

Unit Price

BOLT, HEXAGON SOCK

901110501100 901110501100

5,11 $

Unit Price

GRILL, AIR INTAKE

B34F837R0000 B34F837R0000

102,67 $

Unit Price

NUT, SPRING (6E5)

9018305M0200 9018305M0200

1,61 $

Unit Price

EMBLEME, YAMAHA

BCNF153A0000 BCNF153A0000

Not available

EMBLEME, YAMAHA

BCNF153B0000 BCNF153B0000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the SIDE COVER of your Yamaha XSR 700 XTribute of 2022. Let us know if you have any questions.
