STARTER MOTOR

STARTER CLUTCH FOR YAMAHA XSR 2020

TRANSMISSION

Item numbers

PRIMARY DRIVEN GEA

1WS161500000 1WS161500000

652,77 $

Unit Price

PLATE, THRUST

363161540000 363161540000

12,67 $

Unit Price

BOSS, CLUTCH

1WS163710100 1WS163710100

151,13 $

Unit Price

PLATE, FRICTION

5VY163210000 5VY163210000

32,84 $

Unit Price

PLATE, CLUTCH 2

5VY163250000

5VY163252000

24,27 $

Unit Price

PLATE, FRICTION

5TG163210000 5TG163210000

18,87 $

Unit Price

PRESSURE PLATE ASS

1WS163500000 1WS163500000

127,67 $

Unit Price

BRG, R-B 6001 28MM 28G KY

933060010600

933060010500

24,34 $

Unit Price

SPRING, COMPRESSION(3GM)

90501230E400 90501230E400

9,29 $

Unit Price

BOLT, WITH WASHER

901190626300 901190626300

4,24 $

Unit Price

ENTRETOISE 1

BU3E61810000 BU3E61810000

Not available

ROULEMENT

93310332X900 93310332X900

Not available

PLATE, THRUST

363161540000 363161540000

12,67 $

Unit Price

WASHER, PLATE

902012003000 902012003000

10,87 $

Unit Price

WASHER, CONICAL SPRING

902082000100 902082000100

15,48 $

Unit Price

NUT

901792000700

901792002200

20,13 $

Unit Price

ROD, PUSH 1

1WDE63560000 1WDE63560000

66,20 $

Unit Price

LEVIER DE DEBRAYAGE

BU3E63400000 BU3E63400000

Not available

SPRING, TORSION

905081813200 905081813200

4,55 $

Unit Price

WASHER, PLATE

902011002900 902011002900

2,48 $

Unit Price

CIRCLIP(10W)

990091040000 990091040000

1,64 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the STARTER CLUTCH of your Yamaha XSR 700 35kW A2 of 2020. Let us know if you have any questions.
