SIDE COVER

SWINGARM FOR YAMAHA SR 1991

STEERING

BRAS ARRIERE COMP.

3H0221100100 3H0221100100

Not available

BAGUE

33Y221240000 33Y221240000

Not available

BRG, CYL-CAL ROLLER 28.5G NT

933172220800 933172220800

43,95 $

Unit Price

BEARING, THRUST

933422220500 933422220500

76,43 $

Unit Price

CALE

648455330002 648455330002

Not available

WASHER, PLATE

648455330003

902012228404

0,53 $

Unit Price

COVER, THRUST 2

2K8221290000 2K8221290000

20,81 $

Unit Price

SEAL, GUARD

431221510300 431221510300

21,01 $

Unit Price

OIL SEAL (35X41.5X8-483)

931083500400 931083500400

17,66 $

Unit Price

SHAFT, PIVOT

33Y221410100 33Y221410100

79,26 $

Unit Price

NUT (2J2)

901791625600 901791625600

23,51 $

Unit Price

CHAIN CASE

2J2223110100 2J2223110100

121,77 $

Unit Price

BOLT, HEXAGON DEEP RECESS

973130601600

97D950601600

1,96 $

Unit Price

WASHER(6A1)

929900610000

929950610000

1,46 $

Unit Price

BOLT (4MY)

970010602000

970070602000

2,42 $

Unit Price

GROMMET

904801339800

904801301400

4,52 $

Unit Price

COLLAR (3H5)

903870621600

90387060A300

3,09 $

Unit Price

WASHER, PLATE 1012832300

902010606600 902010606600

4,68 $

Unit Price

BOLT, FLANGE(2UJ)

950230601000

950240601000

2,41 $

Unit Price

AMORTISSEUR, ARRIERE

48U222100000 48U222100000

Not available

WASHER PLATE 148272190000

902011421500 902011421500

5,87 $

Unit Price

WASHER, PLATE (2J2)

902011069600 902011069600

4,32 $

Unit Price

WASHER, PLATE (2J2)

902011069600 902011069600

4,32 $

Unit Price

NUT, CAP (371)

901761000900 901761000900

5,07 $

Unit Price

NUT, CROWN(3BM)

901761001300

901761007300

10,48 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the SWINGARM of your Yamaha SR500 of 1991. Let us know if you have any questions.
