STARTER CLUTCH

TRANSMISSION FOR YAMAHA MBK XLIMIT 2002

GEAR SHIFT SELECTOR DRUM / FORKS

Item numbers

ARBRE, PRIMAIRE

4YVE74110000 4YVE74110000

Not available

5EME PIGNON PRIMAIRE

4YVE71510000 4YVE71510000

Not available

3EME PIGNON PRIMAIRE

4YVE71310000 4YVE71310000

Not available

6EME PIGNON PRIMAIRE

4YVE71610000 4YVE71610000

Not available

2EME PIGNON PRIMAIRE

4YVE71210000 4YVE71210000

Not available

JONC

1TLE65290000 1TLE65290000

Not available

CIRCLIP, TYPE S

934401881600 934401881600

Not available

93306-20310-00 *

93306203Y000 93306203Y000

14,31 $

Unit Price

BEARING, CYLINDRIC

933152142900 933152142900

33,57 $

Unit Price

ARBRE, SECONDAIRE

4YVE74210000 4YVE74210000

Not available

1ERE PIGNON SECONDAIRE

4YVE72110000 4YVE72110000

Not available

5EME PIGNON SECONDAIRE

4YVE72510000 4YVE72510000

Not available

4EME PIGNON SECONDAIRE

4YVE72410000 4YVE72410000

Not available

3EME PIGNON SECONDAIRE

4YVE72310000 4YVE72310000

Not available

6EME PIGNON SECONDAIRE

4YVE72610000 4YVE72610000

Not available

2EME PIGNON SECONDAIRE

4YVE72210000 4YVE72210000

Not available

CIRCLIP, TYPE S

934402082500 934402082500

Not available

RONDELLE, PLATE

90201148L600 90201148L600

Not available

JONC

1TLE65290000 1TLE65290000

Not available

RONDELLE, PLATE

90201208L700 90201208L700

Not available

RONDELLE, PLATE

90201208L800 90201208L800

CIRCLIP, TYPE S

934102082500 934102082500

Not available

BEARING, CYLINDRIC

933152142900 933152142900

33,57 $

Unit Price

ROULEMENT

93306204X100 93306204X100

Not available

JOINT SPY

931022087300 931022087300

Not available

PIGNON SORTIE DE B.V.

5BKE74600000 5BKE74600000

Not available

CIRCLIP, TYPE S

934102082500 934102082500

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the TRANSMISSION of your Yamaha X-LIMIT of 2002. Let us know if you have any questions.
