SWITCH / LEVER

ELECTRICAL 1 FOR YAMAHA MBK XLIMIT 2002

BOBINE D'ALLUMAGE

5BKH23100000 5BKH23100000

Not available

BOULON, TETE HEXAGONALE CREUSE

9011006X3500 9011006X3500

Not available

RONDELLE, ONDULEE

9020606X0100 9020606X0100

Not available

PLUG CAP ASSY

1J7823700000 1J7823700000

40,56 $

Unit Price

JOINT

904300982400 904300982400

Not available

CONTACTEUR DE POINT-MORT

3NCH25400000 3NCH25400000

Not available

BATTERIE COMPLET

3HL821100200 3HL821100200

Not available

DURITE DE RENIFLARD

2RH218260000 2RH218260000

Not available

SIEGE, BATTERIE

3HLH21221000 3HLH21221000

Not available

SUPPORT DE FUSIBLE

5T8H21500000 5T8H21500000

Not available

FUSE, 10A

1A0821510000 1A0821510000

5,61 $

Unit Price

FIL, POSITIF

10W821150000 10W821150000

Not available

CONTACTEUR A CLEF COMPLET

5BKH25100000 5BKH25100000

Not available

ECROU, CONTACTEUR PRINCIPAL

4CTH25690000 4CTH25690000

Not available

RESISTANCE CPLT

5BKH53700000 5BKH53700000

Not available

BOULON, TETE HEXAGONALE CREUSE

9011006X1700 9011006X1700

Not available

RONDELLE, ONDULEE

9020606X0100 9020606X0100

Not available

REDRESSEUR REGULATEUR CPLT

5BKH19600000 5BKH19600000

Not available

BOULON, TETE HEXAGONALE CREUSE

9011006X2000 9011006X2000

Not available

RONDELLE 2

3HLF22440000 3HLF22440000

Not available

RONDELLE, ONDULEE

9020606X0100 9020606X0100

Not available

SUPPORT, BATTERIE

3HLH21280000 3HLH21280000

Not available

FAISCEAU DE FILS COMPLET

5BKH25900000 5BKH25900000

Not available

COLLIER, CORDON DE COMMUTATEUR

4VVH39360100 4VVH39360100

Not available

SWITCH CORD BAND

4KHH39360100 4KHH39360100

7,21 $

Unit Price

ETIQUETTE

3HLH23770000 3HLH23770000

Not available

JAUGE A HUILE CPLT

3HL857200100 3HL857200100

Not available

RELAIS DES CLIGNOTANTS CPLT

5BKH33500200 5BKH33500200

Not available

AVERTISSEUR

4CUH33710100 4CUH33710100

Not available

BOULON

9010106X0800 9010106X0800

Not available

RONDELLE, ONDULEE

9020606X0000 9020606X0000

Not available

COMMUTATEUR CPLT

5BKH25300000 5BKH25300000

Not available

CORDON COMMUTATEUR

5BKH27160000 5BKH27160000

Not available

CATADIOPTRE ARRIERE

5BKH51300000 5BKH51300000

Not available

RONDELLE, SPECIALE

5BKH41270000 5BKH41270000

Not available

VIS HEXAGONAL AVC RONDELLE

975070661200 975070661200

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the ELECTRICAL 1 of your Yamaha X-LIMIT of 2002. Let us know if you have any questions.
