STEERING

FUEL TANK FOR YAMAHA XMAX 2017

SEAT

Item numbers

FUEL TANK COMP.

1SDF41101000 1SDF41101000

Not available

. FUEL PUMP COMP.

1SDE39070000 1SDE39070000

Not available

. SENDER ASSY

1SDH57010000 1SDH57010000

Not available

. O-RING

1SD244860000 1SD244860000

Not available

. BRACKET, FUEL PUMP

1SDF44910000 1SDF44910000

Not available

. NUT, CROWN

9017606X0100 9017606X0100

Not available

. INSULATOR, FUEL TANK 2

1SDF416G0000 1SDF416G0000

Not available

. CLIP

1B9F411M0000 1B9F411M0000

Not available

BOLT, WITH WASHER

9011906X0700 9011906X0700

Not available

GROMMET(38W)

904800140000 904800140000

15,10 $

Unit Price

GROMMET

9048013X0400 9048013X0400

Not available

COLLAR

9038706X4500 9038706X4500

Not available

COLLAR

9038706X5100 9038706X5100

Not available

CAP ASSY

1GBF46100000 1GBF46100000

Not available

COLLAR

9038706X2700 9038706X2700

Not available

PIPE, OVERFLOW

1SDF43180000 1SDF43180000

Not available

COVER, FILLER

1SDF414A1100 1SDF414A1100

Not available

PIPE 10

1SDF43210000 1SDF43210000

Not available

CLIP

90467090A200 90467090A200

1,47 $

Unit Price

ROLL OVER VALVE ASSY

2C0241800000 2C0241800000

103,54 $

Unit Price

BAND 1

1SDF43980000 1SDF43980000

Not available

BAND, SWITCH CORD

4KHH39360100 4KHH39360100

7,52 $

Unit Price

PIPE 11

1SDF43220000 1SDF43220000

Not available

CLIP

90467090A200 90467090A200

1,47 $

Unit Price

CLAMP

9046412X0100 9046412X0100

Not available

CANISTER ASSY

5WYF41700000 5WYF41700000

Not available

BOLT

9010906X1800 9010906X1800

Not available

NUT, SPRING

9018306X0300 9018306X0300

Not available

PIPE 12

1SDF43230000 1SDF43230000

Not available

CLIP

90467090A200 90467090A200

1,47 $

Unit Price

CLIP 101235600

904670800300 904670800300

5,61 $

Unit Price

PIPE, OVERFLOW

1SDF43180000 1SDF43180000

Not available

CLIP

9046712X0200 9046712X0200

Not available

CLAMP

9046415X0000 9046415X0000

Not available

CLAMP(4GL)

904641023300 904641023300

9,66 $

Unit Price

CLAMP 1

5VU241350000 5VU241350000

20,96 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
