EXHAUST FOR YAMAHA XMAX 2017

CRANKCASE

Item numbers

POT D'ECHAPPEMENT 1

1SD147110000 1SD147110000

Not available

GASKET, SILENCER

5KS147550000 5KS147550000

30,50 $

Unit Price

PROTECTEUR, POT D'ECHAP 1

1SDE47181000 1SDE47181000

Not available

PROTECTEUR DE POT D'ECHAPPT

1SDE47281000 1SDE47281000

Not available

BOLT

901110601500 901110601500

2,69 $

Unit Price

SUPPORT, PROTECTEUR

5RU146290000 5RU146290000

Not available

PROTECTOR WASHER

5GM147660000 5GM147660000

2,80 $

Unit Price

BOLT

913800601200 913800601200

3,28 $

Unit Price

BOUCHON

1SDE47990000 1SDE47990000

Not available

WASHER, PL YBS66-6

929900620000 929900620000

1,61 $

Unit Price

BOLT

901110602000 901110602000

4,66 $

Unit Price

PROTECTEUR DE POT D'ECHAPPT

1SDE47381000 1SDE47381000

Not available

PROTECTEUR DE POT D'ECHAPPT

1SDE47481000 1SDE47481000

Not available

BOLT

901110601500 901110601500

2,69 $

Unit Price

PROTECTOR WASHER

5GM147660000 5GM147660000

2,80 $

Unit Price

WASHER, PLATE 7FK

90201062P700 90201062P700

4,01 $

Unit Price

COUDE D'ECHAPPEMENT

1SDE46110000 1SDE46110000

Not available

EXHAUST PIPE GASKE

4TR146130000 4TR146130000

13,94 $

Unit Price

NUT, SELF-LOCKING

956020820000 956020820000

7,23 $

Unit Price

FLANGE BOLT

90105100A400 90105100A400

13,46 $

Unit Price

GASKET

5RU148150000 5RU148150000

3,39 $

Unit Price

DURITE 1

1SD148710000 1SD148710000

Not available

HEXAGON SOCKET HEA

901100621900 901100621900

0,98 $

Unit Price

DURITE 2

1SDE48810000 1SDE48810000

Not available

JONC

9046808X0100 9046808X0100

Not available

95801-06012-00 *

958020601200 958020601200

1,33 $

Unit Price

CLAPET COMPLET

5RU148031000 5RU148031000

Not available

SUPPORT

1SDE48340000 1SDE48340000

Not available

BOLT, FLANGE

950220601600 950220601600

1,22 $

Unit Price

DURITE 2

1SDE48820000 1SDE48820000

Not available

90467-15M14-00 *

904671619500 904671619500

8,19 $

Unit Price

CLIP

904671700300 904671700300

3,28 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
