CYLINDER FOR YAMAHA XMAX 2017

CRANKSHAFT / PISTON

Item numbers

JEU DE CULASSE

1SDE11012000 1SDE11012000

Not available

VALVE GUIDE, INTAK

5JW111331000 5JW111331000

84,20 $

Unit Price

VALVE GUIDE, EXHAU

3P6111341000 3P6111341000

106,84 $

Unit Price

. BOULON

9010506X4400 9010506X4400

Not available

PLUG, STRAIGHT SCR

903401200700 903401200700

5,85 $

Unit Price

GOUJON

9011608X0500 9011608X0500

Not available

BOUGIE BOUGIE (NGK CR7E)

9470100X0900 9470100X0900

Not available

CYLINDER HEAD GASK

5RU111810000 5RU111810000

80,25 $

Unit Price

BOLT

913180615000 913180615000

12,10 $

Unit Price

RONDELLE, PLATE

9020106X2900 9020106X2900

Not available

NUT

901791000600 901791000600

10,40 $

Unit Price

NUT, CROWN(2GG)

901761007500 901761007500

9,63 $

Unit Price

RONDELLE, PLATE

9020110X2200 9020110X2200

Not available

DOWEL PIN

995301001400 995301001400

6,45 $

Unit Price

COUVERCLE, CULASSE 1

1SDE11910000 1SDE11910000

Not available

GASKET, HEAD COVER

5RU111930000 5RU111930000

16,78 $

Unit Price

BRIDE

904621200700 904621200700

Not available

CLAMP

904640901700 904640901700

6,79 $

Unit Price

PLUG

5RU111380000 5RU111380000

14,64 $

Unit Price

GUIDE, BUTEE 3

1SDE22210000 1SDE22210000

Not available

BOLT, FLANGE

950220603000 950220603000

1,41 $

Unit Price

BOLT (4BP)

90109066F000 90109066F000

9,73 $

Unit Price

5EA-1111G-00-00 *

4KG1111G0000 4KG1111G0000

22,76 $

Unit Price

BOULON

9010506X3400 9010506X3400

Not available

RONDELLE, PLATE

9020106X0900 9020106X0900

Not available

CYLINDER

5RU113102100 5RU113102100

725,61 $

Unit Price

GASKET, CYLINDER

5RU113510000 5RU113510000

26,26 $

Unit Price

JOINT TORIQUE

9321086X0000 9321086X0000

Not available

BOLT, FLANGE

950220603000 950220603000

1,41 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
