CYLINDER

CRANKSHAFT / PISTON FOR YAMAHA KODIAK 2002

VALVE

Item numbers

CRANKSHAFT ASSY

5GH114001000 5GH114001000

774,84 $

Unit Price

CRANKSHAFT 1

5GHW11411000

Not available

CRANKSHAFT 2

5GHW11420000

Not available

PIN, CRANK 1

5GH116810000 5GH116810000

86,20 $

Unit Price

BEARING, CYLINDRICAL (3TB)

93310635D400 93310635D400

138,76 $

Unit Price

WASHER, PLATE(1XL)

90201356K100 90201356K100

16,42 $

Unit Price

ROD, CONNECTING

5GH116510100 5GH116510100

202,04 $

Unit Price

SEAL, CRANK

5GH114470000 5GH114470000

48,01 $

Unit Price

KEY, WOODRUFF

902800504800

902800500100

13,31 $

Unit Price

WASHER, PLATE (856)

902011032100 902011032100

7,83 $

Unit Price

BOLT (21V)

901011056800 901011056800

5,64 $

Unit Price

O-RING (538)

932101629000 932101629000

10,62 $

Unit Price

BEARING(4GB)

933063062900 933063062900

99,23 $

Unit Price

PISTON (STD)

5GH116310000 5GH116310000

141,37 $

Unit Price

PISTON (0.50MM O-S)

5GH116360000 5GH116360000

141,38 $

Unit Price

PISTON (1.00MM O-S)

5GH116380000 5GH116380000

141,37 $

Unit Price

PISTON RING SET (STD)

5GH116030000 5GH116030000

68,52 $

Unit Price

PISTON RING SET (0.50MM O-S)

5GH116050000 5GH116050000

69,34 $

Unit Price

PISTON RING SET (1.00MM O-S)

5GH116070000 5GH116070000

69,34 $

Unit Price

PIN, PISTON

3LD116330000 3LD116330000

22,70 $

Unit Price

CIRCLIP 341116340000

934502202700 934502202700

4,86 $

Unit Price

BRG, R-B 6303 47MM 115G NK

933063031500

933063030200

32,05 $

Unit Price

BRG, R-B 6304C3 52MM 144G KY

933063043800

933063042100

26,73 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CRANKSHAFT / PISTON of your Yamaha YFM400FWA of 2002. Let us know if you have any questions.
