FRONT SUSPENSION / WHEEL

STEERING FOR YAMAHA KODIAK 1994

FUEL TANK

Item numbers

HOLDER, HANDLE UPPER

1E6234410000 1E6234410000

27,38 $

Unit Price

BOLT, FLANGE

958230805000

958170805000

4,26 $

Unit Price

PLUG, TAPER(2HR)

903362805300 903362805300

6,09 $

Unit Price

PLANE BEARING, STEERING

1UY238120000 1UY238120000

25,72 $

Unit Price

OIL SEAL(1UY)

931123101100 931123101100

8,84 $

Unit Price

BRACKET, STEERING LOWER

3GD238680100 3GD238680100

13,62 $

Unit Price

BOLT (663)

970130806000 970130806000

5,17 $

Unit Price

WASHER, LOCK 1

1UY238940100 1UY238940100

3,29 $

Unit Price

COLLAR(85G)

90387106T400 90387106T400

16,16 $

Unit Price

COLLAR(2GU)

90387176R600 90387176R600

15,10 $

Unit Price

WASHER, PLATE (3L6)

902011077400 902011077400

7,77 $

Unit Price

NUT, SELF-LOCKING (8U7)

901851011500 901851011500

3,73 $

Unit Price

PIN, COTTER

914902002000

914902002500

3,75 $

Unit Price

TIE ROD

2HR238310100 2HR238310100

38,04 $

Unit Price

JOINT, UNIVERSAL 2

59V238450100 59V238450100

98,35 $

Unit Price

NUT (682)

953031070000

953801070000

9,14 $

Unit Price

NUT, HEXAGON (8A5)

901701018600 901701018600

7,23 $

Unit Price

TIE ROD

2HR238310100 2HR238310100

38,04 $

Unit Price

JOINT, UNIVERSAL 2

59V238450100 59V238450100

98,35 $

Unit Price

NUT (682)

953031070000

953801070000

9,14 $

Unit Price

NUT, HEXAGON (8A5)

901701018600 901701018600

7,23 $

Unit Price

NUT 3532518200

901711000400 901711000400

6,52 $

Unit Price

PIN, COTTER

914902002000

914902002500

3,75 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the STEERING of your Yamaha YFM400FW of 1994. Let us know if you have any questions.
