CYLINDER HEAD FOR YAMAHA KODIAK 1994

CYLINDER

Item numbers

CYLINDER HEAD ASSY

1UY111100100

1UY111100200

1 316,26 $

Unit Price

GUIDE, INTAKE VALVE

3Y1111331000

3Y1111331100

67,34 $

Unit Price

CIRCLIP (1L9)

934401205200 934401205200

2,28 $

Unit Price

BOLT UNION 137131650000

904010600100 904010600100

8,41 $

Unit Price

GASKET (4V2)

904300619200

904300616600

3,85 $

Unit Price

BOLT, STUD(2NL)

901160650300 901160650300

10,11 $

Unit Price

ABSORBER

583111270000 583111270000

9,51 $

Unit Price

ABSORBER

583111270000 583111270000

9,51 $

Unit Price

ABSORBER

583111270000 583111270000

9,51 $

Unit Price

GASKET, CYLINDER HEAD 1

1UY111810000

1UY111810100

49,22 $

Unit Price

PIN, DOWEL

995301401600 995301401600

8,50 $

Unit Price

GASKET (1L9)

904301413100 904301413100

7,83 $

Unit Price

BOLT, FLANGE

901051068400

901051026000

12,66 $

Unit Price

BOLT, FLANGE

901051068500

901051026100

13,52 $

Unit Price

WASHER PLATE 341839090000

902011012800 902011012800

6,46 $

Unit Price

BOLT, SOCKET

913160805000

913170805000

6,20 $

Unit Price

COUVERCLE LATERAL DE CULASSE 3

3Y1111850000 3Y1111850000

Not available

O-RING (15A)

932110663500 932110663500

16,53 $

Unit Price

BOLT, SOCKET

913160602500

913170602500

4,03 $

Unit Price

COVER, CYLINDER HEAD SIDE 2

3Y1111860000

3Y1111861000

19,21 $

Unit Price

COVER, CYLINDER HEAD SIDE 3

2NL111870000

2NL111871100

15,07 $

Unit Price

O-RING

932105763400 932105763400

16,28 $

Unit Price

BOULON

913165763400 913165763400

Not available

PLATE

3Y11111F0000 3Y11111F0000

9,94 $

Unit Price

BOLT (661)

970130601200 970130601200

5,54 $

Unit Price

WASHER, LOCK (3Y1)

902150616200 902150616200

5,61 $

Unit Price

SPARK PLUG DR8EA

947010015700

947010033300

5,32 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CYLINDER HEAD of your Yamaha YFM400FW of 1994. Let us know if you have any questions.
