FRONT SUSPENSION / WHEEL

STEERING FOR YAMAHA RAPTOR 2011

FUEL TANK

Item numbers

. CORPS, CLE GUIDON

10PF34820000 10PF34820000

Not available

. RESSORT

5CHF348G0000 5CHF348G0000

Not available

. RONDELLE, PLATE

9020103X0200 9020103X0200

Not available

. RIVET

5BKF34680000 5BKF34680000

Not available

. COUVERCLE

10PF319U0000 10PF319U0000

Not available

. SUPPORT, ANTIVOL DE DIRECTION

33BF33260000 33BF33260000

Not available

VIS

9014908X0400 9014908X0400

Not available

BUTEE

33BF33760000 33BF33760000

Not available

SUPPORT 1

33BF334G0000 33BF334G0000

Not available

VIS

9014908X0400 9014908X0400

Not available

PLANE BEARING, STEERING

1UY238120000 1UY238120000

25,72 $

Unit Price

COLLAR(85G)

90387090R000

90387106T400

16,16 $

Unit Price

OIL SEAL(1UY)

931123101100 931123101100

8,84 $

Unit Price

VIS

9014908X0500 9014908X0500

Not available

COLUMN, STEERING 2

4D3238130000 4D3238130000

322,78 $

Unit Price

HOLDER, HANDLE UPPER

8K1238140000

1E6234410000

27,38 $

Unit Price

BOLT, FLANGE(6TA)

958220803000

958170803000

4,16 $

Unit Price

PLANE BEARING, STEERING

1UY238120000 1UY238120000

25,72 $

Unit Price

OIL SEAL(1UY)

931123101100 931123101100

8,84 $

Unit Price

BRACKET, STEERING LOWER

4D3238680000 4D3238680000

16,73 $

Unit Price

BOLT, HEXAGON

970220805500

970170805500

6,83 $

Unit Price

WASHER, LOCK 1

1UY238940100 1UY238940100

3,29 $

Unit Price

COLLAR(85G)

90387090R000

90387106T400

16,16 $

Unit Price

WASHER, PLATE

902011003600 902011003600

5,92 $

Unit Price

NUT, SELF-LOCKING

901851001900 901851001900

1,69 $

Unit Price

COTTER PIN

914012002000 914012002000

3,75 $

Unit Price

ROD, TIE

4D3238310000 4D3238310000

34,45 $

Unit Price

JOINT, UNIVERSAL 1

1UY238410100 1UY238410100

96,68 $

Unit Price

JOINT, UNIVERSAL 2

1UY238450100 1UY238450100

96,68 $

Unit Price

NUT (682)

953021070000

953801070000

9,14 $

Unit Price

NUT

901701001000 901701001000

1,42 $

Unit Price

NUT, CASTLE

901711000100 901711000100

4,23 $

Unit Price

COTTER PIN

914012002000 914012002000

3,75 $

Unit Price

WASHER (25G)

902091022900 902091022900

2,78 $

Unit Price

GROMMET

904801523500 904801523500

7,60 $

Unit Price

SUPPORT, AVERTISSEUR

33BH33780000 33BH33780000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the STEERING of your Yamaha YFM250R of 2011. Let us know if you have any questions.
