GEAR SHIFT SELECTOR DRUM / FORKS

GEAR SHIFT SHAFT / LEVER FOR YAMAHA XT 2016

FRAME

Item numbers

SHIFT SHAFT ASSY

5XT181010300 5XT181010300

126,99 $

Unit Price

SPRING, TORSION

905083213900 905083213900

5,29 $

Unit Price

CIRCLIP(58Y)

990011260000 990011260000

5,87 $

Unit Price

STOPPER LEVER ASSY

4TP181400000 4TP181400000

26,15 $

Unit Price

SPRING, TORSION

905082602000 905082602000

4,14 $

Unit Price

BOLT

901090618900

901090619000

8,01 $

Unit Price

PIN, DOWEL(4GY)

936084322800 936084322800

7,06 $

Unit Price

OIL SEAL (3Y1)

931021420900 931021420900

14,75 $

Unit Price

SHIFT PEDAL ASSY

5XT181101000

5XT181102000

115,65 $

Unit Price

COVER, CHANGE PEDAL

1W6181130000 1W6181130000

14,56 $

Unit Price

NUT(JN5)

953170670000 953170670000

2,10 $

Unit Price

ROD, SHIFT

5XT181151000 5XT181151000

48,15 $

Unit Price

NUT

901700602200 901700602200

0,71 $

Unit Price

ARM, SHIFT

5XT181121000 5XT181121000

83,78 $

Unit Price

BOLT

5XT274340000

5XT274341000

14,57 $

Unit Price

WASHER, WAVE (17W)

902061207400 902061207400

3,94 $

Unit Price

WASHER, PLATE (3L7)

902010878400 902010878400

3,90 $

Unit Price

BOLT, HEXAGON

970270602000

970170602000

2,42 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
