INTAKE

CARBURETOR FOR YAMAHA TTR 2024

EXHAUST

Item numbers

CARBURETOR ASSY 1

1C6143011000 1C6143011000

823,71 $

Unit Price

VALVE, THROTTLE 2

1XL143132700 1XL143132700

121,81 $

Unit Price

NEEDLE SET

1C61490J0000 1C61490J0000

59,36 $

Unit Price

MAIN NOZZLE

1C6143410000 1C6143410000

37,13 $

Unit Price

MAIN JET 125

288143436300 288143436300

13,43 $

Unit Price

PILOT JET 36

1C6143421800 1C6143421800

16,63 $

Unit Price

PILOT SCREW SET

1C6141050000 1C6141050000

17,20 $

Unit Price

NEEDLE VALVE ASSY

30S143900000 30S143900000

52,85 $

Unit Price

GASKET

360245120000 360245120000

9,12 $

Unit Price

FLOAT

25N143850000 25N143850000

35,32 $

Unit Price

6E5-14386-01-00 *

689143860000 689143860000

10,04 $

Unit Price

BRACKET 1

4PT142911000 4PT142911000

275,77 $

Unit Price

PAN HEAD SCREW

4PT143250000 4PT143250000

2,55 $

Unit Price

FLOAT CHAMBER GASK

5Y1143840000 5Y1143840000

26,33 $

Unit Price

98580-04014-00 *

976010411400 976010411400

3,72 $

Unit Price

GASKET

5Y1141980000 5Y1141980000

14,71 $

Unit Price

STOP SCREW SET

5DS1490K0000 5DS1490K0000

15,68 $

Unit Price

CLIP

5Y1141590000 5Y1141590000

4,61 $

Unit Price

PAN HEAD SCREW

30S143250000 30S143250000

2,59 $

Unit Price

GASKET

5Y1145360000 5Y1145360000

14,71 $

Unit Price

STARTER PLUNGER

1KH143710100 1KH143710100

70,89 $

Unit Price

PLATE

5Y1141460000 5Y1141460000

36,33 $

Unit Price

PLATE

42U141460000 42U141460000

3,22 $

Unit Price

PIPE

1KH141490000 1KH141490000

12,34 $

Unit Price

PIPE

1C6141970000 1C6141970000

10,11 $

Unit Price

PIPE

1C6143960000 1C6143960000

6,56 $

Unit Price

14T-14104-00-00 *

14T143230000 14T143230000

11,43 $

Unit Price

DIAPHRAGM SET 1

5Y11490A0000 5Y11490A0000

49,08 $

Unit Price

98503-04010-00 *

985010401000 985010401000

5,02 $

Unit Price

WASHER, MAIN JET

1KH141530000 1KH141530000

14,92 $

Unit Price

98580-05012-00 *

978010501200 978010501200

3,04 $

Unit Price

NUT

30X143580000 30X143580000

2,52 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CARBURETOR of your Yamaha TT-R 230 of 2024. Let us know if you have any questions.
