ELECTRICAL 1

ELECTRICAL 2 FOR YAMAHA XSR 2018

ELECTRICAL 3

Item numbers

GASKET

904301000400 904301000400

3,62 $

Unit Price

THERMO SENDER UNIT

4P9835910000 4P9835910000

36,73 $

Unit Price

REFLECTOR, 1

4AG851110000 4AG851110000

15,16 $

Unit Price

95701-06500-00 *

957020650000 957020650000

3,05 $

Unit Price

BRACKET, REFLECTOR 1

B90851120000 B90851120000

Not available

BRACKET, REFLECTOR 2

B90851220000 B90851220000

Not available

MAIN SW. IMMOBILIZER KIT

B90W82506000 B90W82506000

Not available

. ENGINE CONTROL UNIT ASSY

B908591A6000 B908591A6000

Not available

. IMMOBILIZER. UNIT COMP.

1RC8255P0000 1RC8255P0000

Not available

SCREW

5SL821130100 5SL821130100

2,42 $

Unit Price

KEY, BLANK

5SL825110800 5SL825110800

34,81 $

Unit Price

IGNITION COIL ASSY

1RC823100000 1RC823100000

165,71 $

Unit Price

1RC-82540-01-00 *

1RC825400000 1RC825400000

134,76 $

Unit Price

O-RING

932102100100 932102100100

2,92 $

Unit Price

90110-05038-00 *

901100506700 901100506700

1,60 $

Unit Price

OIL LEVEL GAUGE AS

5S7857200000 5S7857200000

131,90 $

Unit Price

O-RING

5VY8A8E00000 5VY8A8E00000

14,18 $

Unit Price

BOLT, FLANGE

950220601600 950220601600

1,22 $

Unit Price

CLAMP

904650805300 904650805300

4,90 $

Unit Price

PLUG, BLIND

3P6153990000 3P6153990000

32,24 $

Unit Price

O-RING

932101556600 932101556600

5,38 $

Unit Price

91317-06016-00 *

901100616100 901100616100

3,37 $

Unit Price

90109-08196-00 *

901090819500 901090819500

6,11 $

Unit Price

COVER, MAIN SWITCH

B90825680000 B90825680000

22,39 $

Unit Price

GRILLE, FRONT

B90283090000 B90283090000

27,87 $

Unit Price

NUT, SPRING (6E5)

9018305M0200 9018305M0200

1,61 $

Unit Price

COLLAR

903870902000 903870902000

1,95 $

Unit Price

90111-06095-00 *

901110609000 901110609000

4,74 $

Unit Price

RIVET

902690601800 902690601800

2,59 $

Unit Price

90464-15195-00 *

904641307300 904641307300

4,73 $

Unit Price

CLAMP

904641600100 904641600100

2,72 $

Unit Price

HORN

BS2833710000 BS2833710000

56,19 $

Unit Price

BUTTON HEAD BOLT

920170601000 920170601000

3,84 $

Unit Price

FLASHER RELAY ASSY

4GY833500000 4GY833500000

103,07 $

Unit Price

RELAY ASSY (1ST-00

1ST819500000 1ST819500000

18,82 $

Unit Price

RELAY HOLDER

5JJ819520000 5JJ819520000

9,35 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
