TRANSMISSION

CROSS SHAFT FOR YAMAHA XJ 1987

GEAR SHIFT SELECTOR DRUM / FORKS

PIGNON INTERMED

31AW17510100 31AW17510100

Not available

BRG, R-B 6207 72MM 272G KY

933062070900 933062070900

97,36 $

Unit Price

NUT(2NX)

901791836000

901791855200

21,31 $

Unit Price

CAM, DRIVE

31A175260000

31A175260100

96,38 $

Unit Price

CAM, DRIVEN

31A175270000 31A175270000

73,91 $

Unit Price

RESSORT, COMPRESSION

905010706200 905010706200

Not available

HOLDER

4H7175240000 4H7175240000

53,88 $

Unit Price

WASHER, THRUST

3H5175290000 3H5175290000

3,72 $

Unit Price

WASHER, LOCK(2NX)

902152319400

902152326500

5,49 $

Unit Price

CALE (0.15T)

4H7175370015 4H7175370015

Not available

SHIM, THRUST

4H7175370020 4H7175370020

5,56 $

Unit Price

THRUST SHIM

4H7175370030 4H7175370030

5,58 $

Unit Price

THRUST SHIM

4H7175370040 4H7175370040

5,58 $

Unit Price

CALE, BUTEE

4H7175375000 4H7175375000

Not available

CIRCLIP(1FN)

934404708100

934404514400

4,71 $

Unit Price

BEARING(1FF)

933060050800

933060051900

35,93 $

Unit Price

HOUSING COMP.

31AW17520000 31AW17520000

143,74 $

Unit Price

O-RING (2H7)

932107136000 932107136000

16,40 $

Unit Price

OIL SEAL (4H7)

931013509700 931013509700

24,98 $

Unit Price

BRIDE, TRANSMIS INTERMEDIAIRE

4H7175550000 4H7175550000

Not available

O-RING (2H7)

932101435900 932101435900

7,71 $

Unit Price

WASHER, PLATE (1J7)

902011463300 902011463300

7,77 $

Unit Price

NUT

901791431700 901791431700

22,18 $

Unit Price

CALE (0.10T)

4H7175310010 4H7175310010

Not available

CALE (0.15T)

4H7175310015 4H7175310015

Not available

SHIM, PINION

4H7175310020

3JB175312000

9,27 $

Unit Price

SHIM, PINION

4H7175310030

3JB175313000

9,31 $

Unit Price

SHIM, PINION

4H7175310040

3JB175314000

9,27 $

Unit Price

CALE (0.50T)

4H7175310050 4H7175310050

Not available

BOLT, FLANGE(6TA)

958210803000

958170803000

4,16 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CROSS SHAFT of your Yamaha XJ900F of 1987. Let us know if you have any questions.
