INTAKE

CARBURETOR FOR YAMAHA RAPTOR 2023

EXHAUST

Item numbers

CARBURETOR ASSY 1

BD3E41011000 BD3E41011000

638,73 $

Unit Price

CAP, MIXING CHAMBE

BD3E439D1000 BD3E439D1000

84,72 $

Unit Price

CLIP 1

BD3E439G0000 BD3E439G0000

3,45 $

Unit Price

SPRING, THROTTLE V

BD3E43310000 BD3E43310000

8,73 $

Unit Price

VALVE, THROTTLE

BD3E37310000 BD3E37310000

90,80 $

Unit Price

NEEDLE ASSY

BD3E41500000 BD3E41500000

75,52 $

Unit Price

PIPE, MAIN BLEED

BD3E414G0000 BD3E414G0000

69,27 $

Unit Price

JET, PILOT

BD3E49420000 BD3E49420000

39,17 $

Unit Price

PIN, FLOAT

BD3E43860000 BD3E43860000

9,63 $

Unit Price

VALVE, NEEDLE

BD3E43920000 BD3E43920000

86,75 $

Unit Price

FLOAT

BD3E43850000 BD3E43850000

84,17 $

Unit Price

O-RING

BD3E43970000 BD3E43970000

43,52 $

Unit Price

SCREW, PILOT ADJUS

BD3E42110000 BD3E42110000

24,40 $

Unit Price

JET, MAIN

BD3E415A0000 BD3E415A0000

23,84 $

Unit Price

PIPE 1

BD3E43480000 BD3E43480000

38,52 $

Unit Price

PIPE

BD3E43490000 BD3E43490000

22,16 $

Unit Price

BRACKET

BD3E45811000 BD3E45811000

11,93 $

Unit Price

SCREW, PAN HEAD

BD3E43250000 BD3E43250000

14,11 $

Unit Price

SCREW, ADJUST

BD3E45210000 BD3E45210000

28,50 $

Unit Price

GASKET, FLOAT CHAM

BD3E43840000 BD3E43840000

12,96 $

Unit Price

CLIP 2

BD3E439H1000 BD3E439H1000

1,36 $

Unit Price

CLIP 1

BD3E449C1000 BD3E449C1000

2,59 $

Unit Price

SCREW

BD3E42161000 BD3E42161000

3,46 $

Unit Price

PLUG, BLIND

BD3E443B0000 BD3E443B0000

9,36 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
