REAR SHOCK ABSORBER

STEERING FOR YAMAHA RAPTOR 2004

FOURCHE / WHEEL

Item numbers

FRONT LOWER ARM

3GB235700033 3GB235700033

346,98 $

Unit Price

BUSHING, REAR ARM

307221230000 307221230000

11,99 $

Unit Price

BOLT

901011249800 901011249800

10,36 $

Unit Price

90185-12134-00 *

901851204600 901851204600

10,88 $

Unit Price

90201-124E4-00 *

902011268800 902011268800

7,38 $

Unit Price

AMORTISSEUR

2HX233500036 2HX233500036

Not available

DISTANCE COLLAR

2HX2331U0000 2HX2331U0000

8,18 $

Unit Price

90105-10669-00 *

901051056100 901051056100

10,99 $

Unit Price

NUT, SELF LOCKING

901851009100 901851009100

8,93 $

Unit Price

FLANGE BOLT

901051246000 901051246000

8,86 $

Unit Price

90185-12134-00 *

901851204600 901851204600

10,88 $

Unit Price

ARTICULATION DIRECTION COMP.

3GB235011000 3GB235011000

Not available

SOLID BUSH (2NL)

903811706700 903811706700

12,97 $

Unit Price

93700-06M03-00 *

937000600400 937000600400

11,08 $

Unit Price

ARTICULATION DIRECTION COMP.

3GB235021000 3GB235021000

Not available

SOLID BUSH (2NL)

903811706700 903811706700

12,97 $

Unit Price

93700-06M03-00 *

937000600400 937000600400

11,08 $

Unit Price

SPACER

3GB234480000 3GB234480000

28,50 $

Unit Price

3JN-23517-00-00 *

2NL235170000 2NL235170000

17,34 $

Unit Price

BOLT (55X)

90109104A800 90109104A800

9,21 $

Unit Price

WASHER, PLATE

902010875900 902010875900

3,69 $

Unit Price

NUT 3532518200

901711000400 901711000400

6,25 $

Unit Price

COTTER PIN

914012002000 914012002000

3,60 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the STEERING of your Yamaha YFM80 of 2004. Let us know if you have any questions.
