ENGINE HATCH 1

ENGINE HATCH 2 FOR YAMAHA JET 2005

HULL & DECK

Item numbers

BOWLOCKER ASSY

GU2U475A0000 GU2U475A0000

Not available

PACKING 4

GJ3U266C3100 GJ3U266C3100

27,38 $

Unit Price

ENGINE HATCH LID

GU2U517B50P0

GU2U517B59P0

555,90 $

Unit Price

PACKING 3

GU2U266B3000 GU2U266B3000

Not available

NUT, SPRING(GJ3)

901830690200 901830690200

10,60 $

Unit Price

HINGE, LID

GU26517D0000 GU26517D0000

112,69 $

Unit Price

BOLT, WITH WASHER (EU0)

90119069UJ00

901190691300

2,66 $

Unit Price

PLATE, HINGE LID

GU2U518E0100 GU2U518E0100

1,13 $

Unit Price

YBS66-6 WASHER, PLAIN

9299R0620000

929900620000

1,68 $

Unit Price

NUT, NYLON (EU0)

9572R0630000

957200630000

4,32 $

Unit Price

LOCK, LID

GP76517C0000

F1K6517C0000

124,38 $

Unit Price

SCREW & WASHER

90159059U200

901590591000

3,29 $

Unit Price

HOOK, LID LOCK

GU26517F0100 GU26517F0100

44,24 $

Unit Price

BOLT(7U8)

9708R0602000

970800602000

5,45 $

Unit Price

YBS66-6 WASHER, PLAIN

9299R0620000

929900620000

1,68 $

Unit Price

NUT, NYLON (EU0)

9572R0630000

957200630000

4,32 $

Unit Price

SIDE COVER 1, YELLOW

GU2U377B50P0

GU2U377B59P0

396,36 $

Unit Price

INNER SIDE COVER 1

GU2U377H0100 GU2U377H0100

11,90 $

Unit Price

RIVET, BLIND

902674880200 902674880200

4,85 $

Unit Price

NUT, SPRING(GJ3)

901830690200 901830690200

10,60 $

Unit Price

BOLT WITH WASHER

90119069UH00

Not available

BOLT

90101069U000

9010106M2700

4,47 $

Unit Price

NUT

9538R0670000 9538R0670000

2,39 $

Unit Price

YBS66-6 WASHER, PLAIN

9299R0620000

929900620000

1,68 $

Unit Price

NUT, NYLON (EU0)

9572R0630000

957200630000

4,32 $

Unit Price

SIDE COVER 2

GU2U377C50P0

GU2U377C59P0

602,51 $

Unit Price

INNER SIDE COVER 2

GU2U377J0100 GU2U377J0100

17,24 $

Unit Price

RIVET, BLIND

902674880200 902674880200

4,85 $

Unit Price

NUT, SPRING(GJ3)

901830690200 901830690200

10,60 $

Unit Price

BOLT WITH WASHER

90119069UH00

Not available

BOLT

90101069U000

9010106M2700

4,47 $

Unit Price

NUT

9538R0670000 9538R0670000

2,39 $

Unit Price

YBS66-6 WASHER, PLAIN

9299R0620000

929900620000

1,68 $

Unit Price

NUT, NYLON (EU0)

9572R0630000

957200630000

4,32 $

Unit Price

TRIM

GU2U51620000 GU2U51620000

1,34 $

Unit Price

FRONT COVER, YELLOW

GU2U513M50P0

GU2U513M59P0

202,70 $

Unit Price

RIVET, BLIND

902674880200 902674880200

4,85 $

Unit Price

COVER 2

F0MU516X0000 F0MU516X0000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
