ENGINE HATCH 2

HULL & DECK FOR YAMAHA JET 2004

SHIELD

Item numbers

HOSE (L720)

904451989500 904451989500

Not available

JOINT, HOSE

68N5112T0000 68N5112T0000

66,76 $

Unit Price

HOSE (L500)

904451989600 904451989600

Not available

CLIP, NYLON 1 (GJ1

90601118UF00 90601118UF00

3,25 $

Unit Price

STRAINER, BILGE

GD0U761D0000 GD0U761D0000

Not available

BASE, STRAINER BLI

EW2676180000 EW2676180000

45,12 $

Unit Price

SCREW, TAPPING

9778R5011200 9778R5011200

Not available

CLIP, NYLON 1 (FN8

90601200U100 90601200U100

7,00 $

Unit Price

CLAMP COMP (EU0)

906009173600 906009173600

4,14 $

Unit Price

90267-48931-00 *

90267489U700 90267489U700

10,49 $

Unit Price

CLAMP

904643280100 904643280100

2,34 $

Unit Price

PACKING, HOSE 2

GJ1U75781100 GJ1U75781100

2,26 $

Unit Price

CLIP, NYLON 1 (GD0

906012001600 906012001600

10,51 $

Unit Price

BAND

90601200U400 90601200U400

Not available

THROUGH-HULL CONNE

906048075900 906048075900

25,64 $

Unit Price

GASKET

904301390900 904301390900

Not available

THROUGH-HULL CONNE

906048077500 906048077500

21,47 $

Unit Price

GASKET

904301390900 904301390900

Not available

DRAIN PLUG ASSY

EU0622800000 EU0622800000

56,00 $

Unit Price

DRAIN PLUG

EU0622820000 EU0622820000

14,13 $

Unit Price

O-RING

EU0622830000 EU0622830000

4,06 $

Unit Price

PACKING, DRAIN

EU0622850100 EU0622850100

5,13 $

Unit Price

PAN HEAD SCREW

9788R0502500 9788R0502500

5,93 $

Unit Price

WASHER

9299R0520000 9299R0520000

9,49 $

Unit Price

FLANGE NUT

9572R0530000 9572R0530000

3,45 $

Unit Price

BOWEYE 1

FN8U16240000 FN8U16240000

Not available

95780-08300-00 *

9572R0830000 9572R0830000

11,93 $

Unit Price

WASHER

9299R0820000 9299R0820000

3,63 $

Unit Price

STABILIZER

GH3U883M3000 GH3U883M3000

Not available

PACKING, STABILIZER

GT3U883U0000 GT3U883U0000

Not available

FLANGE NUT

9572R0630000 9572R0630000

7,07 $

Unit Price

WASHER

9299R0620000 9299R0620000

2,95 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the HULL & DECK of your Yamaha XL700 of 2004. Let us know if you have any questions.
