ELECTRICAL 2

ENGINE HATCH 1 FOR YAMAHA JET 2003

ENGINE HATCH 2

Item numbers

COVER, ENGINE HATCH

F0VU516N50P0 F0VU516N50P0

Not available

NUT, SPRING(GJ3)

901830690200 901830690200

10,60 $

Unit Price

BOLT, WITH WASHER

901190685800

90119068B800

55,45 $

Unit Price

NUT, JOINT

F0VU77720000 F0VU77720000

Not available

BOLT, WITH WASHER

901190680300 901190680300

8,76 $

Unit Price

YBS66-6 WASHER, PLAIN

9299R0620000

929900620000

1,68 $

Unit Price

NUT, NYLON (EU0)

9572R0630000

957200630000

4,32 $

Unit Price

BOLT

9708R0603000 9708R0603000

Not available

NUT

9538R0670000 9538R0670000

2,39 $

Unit Price

YBS66-6 WASHER, PLAIN

9299R0620000

929900620000

1,68 $

Unit Price

NUT, NYLON (EU0)

9572R0630000

957200630000

4,32 $

Unit Price

LID HATCH

F0DU517H80P0 F0DU517H80P0

Not available

LOCK

F0D628750000 F0D628750000

42,47 $

Unit Price

PLUG

90605502U200 90605502U200

4,80 $

Unit Price

PIN, HINGE

F0D6517R0000 F0D6517R0000

Not available

HINGE JOINT

F0D6517T0000 F0D6517T0000

Not available

PACKING CASE

F0DU519D0000

F0DU519D0100

10,95 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
