FRONT WHEEL

FRONT BRAKE CALIPER FOR YAMAHA RAPTOR 2014

REAR WHEEL

Item numbers

DISC, BRAKE (LEFT)

4XEF582T1100 4XEF582T1100

100,93 $

Unit Price

BOLT

901090808200

901090808700

4,15 $

Unit Price

CALIPER ASSY (LEFT)

1S32580T0100 1S32580T0100

474,48 $

Unit Price

PISTON ASSY, CALIPER

5TGW00570000 5TGW00570000

106,61 $

Unit Price

CALIPER SEAL KIT

3LCW00475000 3LCW00475000

68,08 $

Unit Price

BOOT 2

1UY259375100 1UY259375100

15,78 $

Unit Price

BOOT, CALIPER

3JD259170000 3JD259170000

10,59 $

Unit Price

SUPPORT, PAD

3JD259190000 3JD259190000

28,15 $

Unit Price

BLEED SCREW KIT

1UYW00485000

36YW00480000

23,50 $

Unit Price

BOLT

1UY259265100 1UY259265100

4,97 $

Unit Price

WASHER, SPRING

1UY259385100 1UY259385100

0,15 $

Unit Price

BOLT

3JD259260000 3JD259260000

5,53 $

Unit Price

NUT

3JD259610000 3JD259610000

10,20 $

Unit Price

BRAKE PAD KIT

1S3W00450000 1S3W00450000

60,20 $

Unit Price

PIN, PAD

5TG259240000 5TG259240000

20,56 $

Unit Price

SHIM, CALIPER

1S3258280000 1S3258280000

19,15 $

Unit Price

CALIPER ASSY (RIGHT)

1S32580U0100 1S32580U0100

474,48 $

Unit Price

PISTON ASSY, CALIPER

5TGW00570000 5TGW00570000

106,61 $

Unit Price

CALIPER SEAL KIT

3LCW00475000 3LCW00475000

68,08 $

Unit Price

BOOT 2

1UY259375100 1UY259375100

15,78 $

Unit Price

BOOT, CALIPER

3JD259170000 3JD259170000

10,59 $

Unit Price

SUPPORT, PAD

3JD259190000 3JD259190000

28,15 $

Unit Price

BLEED SCREW KIT

1UYW00485000

36YW00480000

23,50 $

Unit Price

BOLT

1UY259265100 1UY259265100

4,97 $

Unit Price

WASHER, SPRING

1UY259385100 1UY259385100

0,15 $

Unit Price

BOLT

3JD259260000 3JD259260000

5,53 $

Unit Price

NUT

3JD259610000 3JD259610000

10,20 $

Unit Price

BRAKE PAD KIT

1S3W00451000 1S3W00451000

60,20 $

Unit Price

PIN, PAD

5TG259240000 5TG259240000

20,56 $

Unit Price

SHIM, CALIPER

1S3258280000 1S3258280000

19,15 $

Unit Price

BOLT, FLANGE

901050818400 901050818400

3,70 $

Unit Price

COLLAR

903872000500 903872000500

24,61 $

Unit Price

WASHER, PLATE

902012002200 902012002200

9,23 $

Unit Price

COLLAR(1UY)

90387150R100 90387150R100

12,02 $

Unit Price

NUT, CASTLE

901711400200 901711400200

7,86 $

Unit Price

PIN, COTTER

914023002500

914013002500

5,77 $

Unit Price

RING, WHEEL 1 (LEFT)

5TG2514A0000 5TG2514A0000

12,80 $

Unit Price

SCREW

901490611700 901490611700

2,94 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
