CYLINDER

CRANKSHAFT / PISTON FOR YAMAHA GRIZZLY 2008

VALVE

Item numbers

CRANKSHAFT ASSY

3B4114000000 3B4114000000

982,78 $

Unit Price

CRANK SUB-ASSY 1

3B4114010900 3B4114010900

581,62 $

Unit Price

CRANK SUB-ASSY 2

3B4114020900 3B4114020900

371,47 $

Unit Price

CRANK PIN 1

1S3116810000 1S3116810000

112,89 $

Unit Price

BEARING

933108401700 933108401700

90,62 $

Unit Price

CONNECTING ROD

1S3116510000 1S3116510000

159,87 $

Unit Price

DRIVE GEAR

5KM115361000 5KM115361000

146,40 $

Unit Price

BEARING COVER WASH

5KM115650000 5KM115650000

13,97 $

Unit Price

SPRING, COMPRESSIO

90501220A100 90501220A100

6,85 $

Unit Price

DOWEL PIN

936060900200 936060900200

0,99 $

Unit Price

93410-35M10-00 *

990093540000 990093540000

6,48 $

Unit Price

WOODRUFF KEY

902800500100 902800500100

12,77 $

Unit Price

WASHER, PLATE 10L

90201165H400 90201165H400

10,06 $

Unit Price

NUT

901791600400 901791600400

18,04 $

Unit Price

BEARING

933063081000 933063081000

92,65 $

Unit Price

PISTON (STD)

1S3116311000 1S3116311000

207,00 $

Unit Price

PISTON RING SET ST

1S3116031000 1S3116031000

57,89 $

Unit Price

PISTON PIN

5VK116330000 5VK116330000

46,75 $

Unit Price

CIRCLIP

934502415400 934502415400

1,22 $

Unit Price

SPACER 1

3B4161810000 3B4161810000

92,23 $

Unit Price

SEAL, CRANK

3B4114470000 3B4114470000

35,72 $

Unit Price

WEIGHT 1

3B4114540000 3B4114540000

173,53 $

Unit Price

BALANCER WEIGHT GE

3B4115310000 3B4115310000

169,14 $

Unit Price

DRIVE SPROCKET

3B4133540000 3B4133540000

74,15 $

Unit Price

KEY, STRAIGHT

902820500700 902820500700

11,01 $

Unit Price

NUT

901701800300 901701800300

15,63 $

Unit Price

WASHER, LOCK

902151800100 902151800100

13,44 $

Unit Price

93306-30560-00 *

933063053400 933063053400

75,57 $

Unit Price

93306-30421-00 *

933063043800 933063043800

25,64 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
