SWITCH / LEVER

ELECTRICAL 1 FOR YAMAHA XTZ TENEREABS 2015

ELECTRICAL 2

NUT, FLANGE(7NB)

9570L0650000

957800650000

3,18 $

Unit Price

BOBINE D'ALLUMAGE COMPLET BOBINE D'ALLUMAGE

4GV823100000 4GV823100000

Not available

BOLT

9131M0502000 9131M0502000

1,54 $

Unit Price

RONDELLE

9290M0560000 9290M0560000

Not available

SUPPORT 3

56PH51510000 56PH51510000

Not available

SCREW, WITH WASHER (1W4)

901590601600 901590601600

4,03 $

Unit Price

COLLERETTE

9038706X5300 9038706X5300

Not available

GROMMET(4FW)

904801258100 904801258100

8,62 $

Unit Price

PLUG CAP ASSY

5VK823700000 5VK823700000

88,75 $

Unit Price

RECTIFIER & REGULATOR ASSY

4XY819600000 4XY819600000

252,56 $

Unit Price

WASHER PLATE 137241870000

902010607200 902010607200

2,78 $

Unit Price

PASSE-FIL

9048015X0100 9048015X0100

Not available

BOLT, FLANGE

958070604000

958170604000

3,91 $

Unit Price

COLLAR

903870604200 903870604200

8,89 $

Unit Price

BATTERY YTZ10S

5VY821000000

5VY821000100

313,94 $

Unit Price

SUPPORT, REGULATEUR

11DF12870000 11DF12870000

Not available

BOITIER COMPLET

56PF177G0000 56PF177G0000

Not available

AMORTISSEUR 3, POSITIONNEMENT

5YKF177M0000 5YKF177M0000

Not available

AMORTISSEUR 1, POSITIONNEMENT

56PF17780000 56PF17780000

Not available

SIEGE, BATTERIE

56PH21220000 56PH21220000

Not available

COUVERCLE, BATTERIE

56PH21290000 56PH21290000

Not available

BAND, BATTERY

26H821310000 26H821310000

13,36 $

Unit Price

COLLAR (8G8)

903870664800 903870664800

3,69 $

Unit Price

BOLT, FLANGE

958070601400

958170601400

4,16 $

Unit Price

FIL, NEGATIF

56PH21160000 56PH21160000

Not available

FIL

56PH21170000 56PH21170000

Not available

KIT DE IMMOBILISATEUR

11DW82501000 11DW82501000

Not available

. BLOC DE CONTROL

11D8591A0000 11D8591A0000

Not available

. IMMOBILISATEUR

5YK8255P0000 5YK8255P0000

Not available

SCREW

5SL821130100 5SL821130100

2,52 $

Unit Price

BLANK KEY

5SL825110800 5SL825110800

36,29 $

Unit Price

ISOLATEUR

56PH253D0000 56PH253D0000

Not available

BOLT

901090819500

901090819600

6,37 $

Unit Price

COUVERCLE

56PH25680000 56PH25680000

Not available

BOLT

901110501100 901110501100

5,33 $

Unit Price

FAISCEAU DE FILS COMPLET

56PH25900000 56PH25900000

Not available

FUSE

5JJ821512000 5JJ821512000

6,97 $

Unit Price

FUSE (10A)

5JJ821513000

67F821514000

4,87 $

Unit Price

FUSE (7.5A-BL)

5JJ821510000 5JJ821510000

6,87 $

Unit Price

FUSE (5A)

5JJ821519000

67F821512000

10,74 $

Unit Price

FUSE

5JJ821516000 5JJ821516000

8,05 $

Unit Price

BRIDE

9046432X0000 9046432X0000

Not available

BRIDE

9046490X0000 9046490X0000

Not available

CLAMP

904642500400 904642500400

3,43 $

Unit Price

COUVERCLE, CONNECTEUR

11DH16620000 11DH16620000

Not available

COUVERCLE, CONNECTEUR

1D0H16620000 1D0H16620000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the ELECTRICAL 1 of your Yamaha XT660ZA of 2015. Let us know if you have any questions.
