FUEL TANK

SEAT FOR YAMAHA XTZ TENERE 2012

FRONT WHEEL

Item numbers

SELLE SEMI-BIPLACE

11DF47703000 11DF47703000

Not available

COUVRE, SELLE

11DF47312000 11DF47312000

Not available

COUVRE, SELLE

11DF47313000 11DF47313000

Not available

PAD, SEAT

5YKF47410000 5YKF47410000

11,87 $

Unit Price

ANTIVOL DE SELLE

5ADF47800000 5ADF47800000

Not available

SUPPORT

11DF175H0000 11DF175H0000

Not available

BOLT, FLANGE

901050501600 901050501600

0,90 $

Unit Price

BOLT, BUTTON

920170602000 920170602000

4,00 $

Unit Price

RONDELLE, PLATE

9020106X0400 9020106X0400

Not available

ECROU, RESSORT

901830581200 901830581200

Not available

CABLE, CROCHET DE SIEGE

11DF478E0000 11DF478E0000

Not available

SEAT LOCK ASSY

2TVW24700000

3CKW24700000

104,25 $

Unit Price

BOLT, BUTTON HEAD

920170601400 920170601400

4,00 $

Unit Price

PLUG

903380500800 903380500800

3,09 $

Unit Price

CACHE, ARRIERE 1

11DF471K0000 11DF471K0000

Not available

MARQUE

11DF176B0000 11DF176B0000

Not available

BOULON

9011106X1900 9011106X1900

Not available

COLLERETTE

9038706X0100 9038706X0100

Not available

NUT, U FLANGE

956020620000

956040620000

4,30 $

Unit Price

POIGNEE DE MAINTIEN

11DF474A0000 11DF474A0000

Not available

POIGNEE DE MAINTIEN 2

11DF474W0000 11DF474W0000

Not available

BOLT, FLANGE(6TA)

958170803000 958170803000

4,16 $

Unit Price

COUVERCLE

11DF44810000 11DF44810000

Not available

COUVERCLE 1

11DF48450100 11DF48450100

Not available

COUVERCLE 2

11DF48460100 11DF48460100

Not available

SCREW, TRUSS TAP.

977074001000 977074001000

0,52 $

Unit Price

COUVERCLE 3

11DF48440000 11DF48440000

Not available

SCREW, TRUSS TAP.

977074001400 977074001400

0,91 $

Unit Price

BAND

11DF483H0000

Not available

MANUEL D'UTILISATION

56PF8199E000 56PF8199E000

Not available

MANUEL D'UTILISATION

56PF8199F000 56PF8199F000

Not available

MANUEL D'UTILISATION

56PF8199G000 56PF8199G000

Not available

MANUEL D'UTILISATION

56PF8199H000 56PF8199H000

Not available

MANUEL D'UTILISATION

56PF8199S000 56PF8199S000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
