SWINGARM FOR YAMAHA XTZ TENERE 2011

REAR SHOCK ABSORBER

Item numbers

BRAS ARRIERE COMP.

11DF21100000 11DF21100000

Not available

BEARING, CYLINDRIC

933152225100 933152225100

55,89 $

Unit Price

BUSH, SOLID

903802211100 903802211100

21,55 $

Unit Price

OIL SEAL

931062201900 931062201900

13,44 $

Unit Price

COVER

30X2219X0000 30X2219X0000

17,82 $

Unit Price

OIL SEAL 35X41.5X8

931083500400 931083500400

16,94 $

Unit Price

BAGUE

11DF21230000 11DF21230000

Not available

AXE, PIVOT

4YR221411000 4YR221411000

Not available

U-NUT, FLANGE

956041620000 956041620000

39,39 $

Unit Price

WASHER, PLATE

902011602100 902011602100

4,56 $

Unit Price

BEARING, CYLINDRIC

933172174600 933172174600

34,43 $

Unit Price

OIL SEAL

931091707100 931091707100

5,08 $

Unit Price

COLLAR (4BH)

90387126Y100 90387126Y100

24,13 $

Unit Price

BRAS DE LIAISON

11DF217A0000 11DF217A0000

Not available

BRAS 1

5JNF217M0000 5JNF217M0000

Not available

BEARING, CYLINDRIC

933172174600 933172174600

34,43 $

Unit Price

BEARING, CYLINDRIC

933173177100 933173177100

36,34 $

Unit Price

BEARING

933153175800 933153175800

39,01 $

Unit Price

OIL SEAL

931091707100 931091707100

5,08 $

Unit Price

COLLAR (4BH)

90387126Y100 90387126Y100

24,13 $

Unit Price

BOULON

9010912X0000 9010912X0000

Not available

NUT, SELF-LOCKING

901851211900 901851211900

10,88 $

Unit Price

WASHER, PLATE

90201124G900 90201124G900

7,60 $

Unit Price

BOLT

901011200200 901011200200

14,08 $

Unit Price

U-NUT 4PM

956171210000 956171210000

12,17 $

Unit Price

COLLAR (3FV)

90387124V000 90387124V000

16,68 $

Unit Price

WASHER, PLATE

90201124G900 90201124G900

7,60 $

Unit Price

COLLAR (3TJ)

90387127W000 90387127W000

17,98 $

Unit Price

JOINT, PROTECTEUR

11DF21510000 11DF21510000

Not available

SCREW 1

1C3229691000 1C3229691000

1,88 $

Unit Price

BRIDE DE DURITE

11DF18230000 11DF18230000

Not available

BOLT, FLANGE (4MY)

950270601200 950270601200

2,01 $

Unit Price

CASE, CHAIN

11DF23110000 11DF23110000

114,09 $

Unit Price

SCREW 1

1C3229691000 1C3229691000

1,88 $

Unit Price

90269-08069-00 *

902690806600 902690806600

3,65 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the SWINGARM of your Yamaha XT660Z of 2011. Let us know if you have any questions.
