Displacement

Year

Model

Finish line

Parts catalogue

Parts diagram

FRAME

FENDER FOR YAMAHA XTR 2011

SIDE COVER

GARDE BOUE AV

5VKF15114000 5VKF15114000

COLLAR(3SX)

90387065X700 90387065X700

9,72 $

Unit Price

COLLAR(50M)

90387087L000 90387087L000

9,08 $

Unit Price

BOLT, WITH WASHER (30X)

901190609600 901190609600

3,94 $

Unit Price

GARDE BOUE AV 2

5VKF15560000 5VKF15560000

Not available

SUPPORT 1

5VKF15870000 5VKF15870000

Not available

BOLT, WITH WASHER

901190605100 901190605100

2,36 $

Unit Price

GARDE BOUE AR

5VKF16110100 5VKF16110100

Not available

DAMPER

5DM283710000 5DM283710000

0,33 $

Unit Price

BOLT, FLANGE

958070601200

958170601200

1,39 $

Unit Price

NUT, SPRING (26H)

901830602300 901830602300

9,95 $

Unit Price

SCREW, TRUSS TAP.

977076002000 977076002000

0,71 $

Unit Price

PLUG(4BP)

903380822600 903380822600

2,64 $

Unit Price

SUPPORT, IMMATRICULATION

5VKF16850000 5VKF16850000

Not available

BOLT, WITH WASHER(81H)

901190611800 901190611800

3,94 $

Unit Price

NUT, SPRING (26H)

901830602300 901830602300

9,95 $

Unit Price

BOLT, FLANGE

958070601400

958170601400

4,16 $

Unit Price

COLLAR (8G8)

903870664800 903870664800

3,69 $

Unit Price

CACHE DE GARDE BOUE AR

5VKF16516000 5VKF16516000

Not available

RIVET

902690806600

902690806900

3,81 $

Unit Price

BOITIER

5VKF160E0000 5VKF160E0000

Not available

AMORTISSEUR 2

5VK216390000 5VK216390000

Not available

BOLT(4GV)

970070501200

970170501200

3,46 $

Unit Price

COLLERETTE

903870580300 903870580300

Not available

PAD, SEAT

1T4247410000 1T4247410000

5,56 $

Unit Price

CLAMP

904640725900 904640725900

2,39 $

Unit Price

BAND, TOOL

4XV213760000 4XV213760000

13,44 $

Unit Price

BAND, TOOL

3YX213760000 3YX213760000

18,96 $

Unit Price

AMORTISSEUR

5VK216490000 5VK216490000

Not available

EMBLEME, YAMAHA

10SF153A2000 10SF153A2000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FENDER of your Yamaha XT660R of 2011. Let us know if you have any questions.

Select your Yamaha XTR model from 2011
