FUEL TANK FOR YAMAHA XTX 2010

SEAT

Item numbers

FUEL TANK COMP.

10SF411000P0 10SF411000P0

Not available

BRACKET, FUEL PUMP

5VKF44910000 5VKF44910000

Not available

O-RING

5JW244860000

19B244860100

48,00 $

Unit Price

BOLT, SOCKET

913170501000 913170501000

2,62 $

Unit Price

CAP ASSY

5VK246020000

5VK246022000

251,07 $

Unit Price

DAMPER, LOCATING 1

3TB241810000 3TB241810000

14,09 $

Unit Price

DAMPER, LOCATING 2

5VK241820000 5VK241820000

WASHER, SPECIAL

5VKF41860000 5VKF41860000

Not available

BOLT, FLANGE

958270601200

958170601200

1,39 $

Unit Price

DAMPER, LOCATING 3

5VK241830000 5VK241830000

Not available

SCOOP, AIR 1

10SF137W0000 10SF137W0000

Not available

DAMPER, PLATE 1

5VK2414H0000 5VK2414H0000

Not available

BOLT

901110501100 901110501100

5,33 $

Unit Price

NUT, SPRING

9018306X0000 9018306X0000

8,62 $

Unit Price

BOLT, FLANGE

901050684100 901050684100

Not available

SCOOP, AIR 2

10SF137X0000 10SF137X0000

Not available

DAMPER, PLATE 1

5VK2414H0000 5VK2414H0000

Not available

BOLT

901110501100 901110501100

5,33 $

Unit Price

NUT, SPRING

9018306X0000 9018306X0000

8,62 $

Unit Price

BOLT, FLANGE

901050684100 901050684100

Not available

GUIDE, AIR

5VKF137Y0000 5VKF137Y0000

Not available

DAMPER

5VK283710000 5VK283710000

Not available

GROMMET(41Y)

904800114100

904800140100

4,92 $

Unit Price

INSULATOR, FUEL TANK 1

5VK2416F0000 5VK2416F0000

Not available

EMBLEM

5VKF413B0100 5VKF413B0100

Not available

EMBLEM

5VKF413B0100 5VKF413B0100

Not available

GRAPHIC, SCOOP AIR SET 1

10SF137C6000 10SF137C6000

Not available

GRAPHIC, SCOOP AIR SET 2

10SF137D6000 10SF137D6000

Not available

LABEL, WARNING

5WWF15680100 5WWF15680100

Not available

LABEL, CAUTION

5DNF415A1000 5DNF415A1000

Not available

FUEL PUMP COMP.

5VK139070200 5VK139070200

1 411,35 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
