TRANSMISSION

GEAR SHIFT SELECTOR DRUM / FORK FOR YAMAHA XTR 2010

GEAR SHIFT SHAFT / LEVER

Item numbers

SHIFT CAM ASSY

5VKE85401000 5VKE85401000

Not available

. SPRING, COMPRESSION

9050106X0000 9050106X0000

Not available

. POINT, NEUTRAL

5VKE85420000 5VKE85420000

Not available

. PLATE, SIDE 2

5VKE85660000 5VKE85660000

Not available

. SCREW

9014905X0500 9014905X0500

Not available

FORK, SHIFT 1

5VKE85010000 5VKE85010000

Not available

FORK, SHIFT 2

5VKE85020000 5VKE85020000

Not available

FORK, SHIFT 3

5VKE85030000 5VKE85030000

HANGER, SPRING

5VKE81440000 5VKE81440000

Not available

SPRING HOOK

132163460000 132163460000

2,95 $

Unit Price

STOPPER LEVER ASSY

5JW181400000 5JW181400000

61,85 $

Unit Price

SCREW STOPPER

5VK181270000 5VK181270000

12,16 $

Unit Price

BEARING, ROLLER 6G

933151120600 933151120600

22,00 $

Unit Price

OIL SEAL 12X22X5-3

931021210600 931021210600

14,20 $

Unit Price

99006-10600-00 *

990011060000 990011060000

4,11 $

Unit Price

WASHER, PLATE

9020112X0600 9020112X0600

Not available

CIRCLIP

9341017X0000 9341017X0000

Not available

WASHER, PLATE

9020117X0100 9020117X0100

Not available

WASHER, PLATE

9020112X0500 9020112X0500

Not available

BOSS 1

5VKE86990000 5VKE86990000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
