CYLINDER

CRANKSHAFT / PISTON FOR YAMAHA XTR 2010

VALVE

Item numbers

CRANKSHAFT ASSY

5VKE14001000 5VKE14001000

Not available

. CRANK 1

5VKE14121000 5VKE14121000

Not available

. CRANK 2

5VKE14221000 5VKE14221000

Not available

5VK-11681-01-00 *

5VK116810000 5VK116810000

108,16 $

Unit Price

93310-84017-00 *

933108401000 933108401000

90,62 $

Unit Price

. ROD, CONNECTING

5VK116510000 5VK116510000

Not available

WOODRUFF KEY

902800500100 902800500100

12,77 $

Unit Price

WASHER, PLATE

902011601300 902011601300

15,09 $

Unit Price

NUT(10L)

901791644800 901791644800

20,46 $

Unit Price

BEARING

93306308Y000 93306308Y000

Not available

PISTON (STD)

5VK116310000 5VK116310000

373,44 $

Unit Price

CP - PISTON RING S

5VK116030000 5VK116030000

104,34 $

Unit Price

PISTON PIN

5VK116330000 5VK116330000

46,75 $

Unit Price

CIRCLIP

934502482400 934502482400

1,67 $

Unit Price

WASHER, PLATE

9020130X0000 9020130X0000

Not available

GEAR, DRIVE

5VKE15360000 5VKE15360000

Not available

GEAR, BALANCE WEIGHT

5VKE15310000 5VKE15310000

Not available

WEIGHT 1

5VKE14540000 5VKE14540000

Not available

BEARING

93306305YJ00 93306305YJ00

Not available

BEARING

93306305YH00 93306305YH00

Not available

OIL SEAL

931012510600 931012510600

12,25 $

Unit Price

KEY, STRAIGHT 36F

902820505800 902820505800

2,65 $

Unit Price

NUT

901701800300 901701800300

15,63 $

Unit Price

WASHER, LOCK

9021518X0000 9021518X0000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
