FRONT FORK

FUEL TANK FOR YAMAHA XTX 2009

SEAT

Item numbers

RESERVOIR A ESSENCE

10SF411000P0 10SF411000P0

Not available

SUPPORT, POMPE A ESSENCE

5VKF44910000 5VKF44910000

Not available

O-RING

5JW244860000

19B244860100

48,00 $

Unit Price

BOLT, SOCKET

913170501000 913170501000

2,62 $

Unit Price

CAP ASSY

5VK246020000

5VK246022000

251,07 $

Unit Price

DAMPER, LOCATING 1

3TB241810000 3TB241810000

14,09 $

Unit Price

SILENT-BLOC

5VK241820000 5VK241820000

RONDELLE, SPECIALE

5VKF41860000 5VKF41860000

Not available

BOLT, FLANGE

958270601200

958170601200

1,39 $

Unit Price

SILENT-BLOC

5VK241830000 5VK241830000

Not available

PLAQUE, A AIR 1

10SF137W3000 10SF137W3000

MOULURE, COUVERCLE DE PANNEAU

5VK2414H0000 5VK2414H0000

Not available

BOLT

901110501100 901110501100

5,33 $

Unit Price

NUT, SPRING

9018306X0000 9018306X0000

8,62 $

Unit Price

BOULON

901050684100 901050684100

Not available

PLAQUE, A AIR 2

10SF137X3000 10SF137X3000

Not available

MOULURE, COUVERCLE DE PANNEAU

5VK2414H0000 5VK2414H0000

Not available

BOLT

901110501100 901110501100

5,33 $

Unit Price

NUT, SPRING

9018306X0000 9018306X0000

8,62 $

Unit Price

BOULON

901050684100 901050684100

Not available

GUIDE A AIR

5VKF137Y0000 5VKF137Y0000

Not available

AMORTISSEUR

5VK283710000 5VK283710000

Not available

GROMMET(41Y)

904800114100

904800140100

4,92 $

Unit Price

ISOLATEUR, RESERVOIR A ESSENCE

5VK2416F0000 5VK2416F0000

Not available

EMBLEME

5VKF413B0100 5VKF413B0100

Not available

EMBLEME

5VKF413B0100 5VKF413B0100

Not available

JEU D'EMBLEME, PLAQUE A AIR1

10S2137C8000 10S2137C8000

Not available

JEU D'EMBLEME, PLAQUE A AIR 2

10S2137D8000 10S2137D8000

Not available

ETIQUETTE, AVERTISSEMENT

5WWF15680100 5WWF15680100

Not available

ETIQUETTE, RECOMMANDATION

5DNF415A1000 5DNF415A1000

Not available

FUEL PUMP COMP.

5VK139070200 5VK139070200

1 411,35 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
