CAMSHAFT / TIMING CHAIN

WATERPUMP / HOSES FOR YAMAHA XTR 2004

RADIATOR / HOSES

ENGRENAGE, MENANT

5VK124360000 5VK124360000

Not available

AXE DE ROTOR

5VK124500000 5VK124500000

Not available

COUVERCLE DE CARTER DE POMPE

5VK124220000 5VK124220000

Not available

O-RING (2HT)

932106175000 932106175000

9,70 $

Unit Price

93306-00105-00 *

933060010600 933060010600

23,35 $

Unit Price

CARTER, POMPE A EAU

5VK124210000 5VK124210000

Not available

BOLT, SMALL FLANGE

950270602500 950270602500

2,39 $

Unit Price

OIL SEAL 12X21X4-4

931011217300 931011217300

14,97 $

Unit Price

MECHANICAL SEAL

11H124381000 11H124381000

30,76 $

Unit Price

WASHER, PLATE 525

902011254100 902011254100

6,27 $

Unit Price

JOINT, COUVERCLE DE CARTER 2

5VK124280000 5VK124280000

Not available

GASKET 25611396000

904300601400 904300601400

Not available

DOWEL PIN

936031621900 936031621900

3,65 $

Unit Price

IMPELLER SHAFT GEA

5VK124590000 5VK124590000

42,30 $

Unit Price

CIRCLIP (10Y)

990091240000 990091240000

3,44 $

Unit Price

RACCORD 1

5VKE24690000 5VKE24690000

Not available

BOLT (4FL)

913170602000 913170602000

3,84 $

Unit Price

JOINT TORIQUE

9321033X0000 9321033X0000

Not available

DURITE 1

5VK124810000 5VK124810000

Not available

JOINT TORIQUE

9321021X0000 9321021X0000

Not available

BOLT (4MY)

913170601200 913170601200

4,89 $

Unit Price

TUYAU 2

5VK125770000 5VK125770000

Not available

JONC

904672980000 904672980000

Not available

BOLT (4MY)

913170605000 913170605000

4,99 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the WATERPUMP / HOSES of your Yamaha XT660R of 2004. Let us know if you have any questions.
