CLUTCH

CLUTCH 2 FOR YAMAHA TMAX 2023

TRANSMISSION

Item numbers

PRIMARY SHEAVE ASSY

B7M176010900 B7M176010900

Not available

OIL SEAL

931013500100 931013500100

25,50 $

Unit Price

WEIGHT

5VU176321000 5VU176321000

CAM

BC3176230000 BC3176230000

Not available

SLIDER

59C176530100 59C176530100

9,49 $

Unit Price

V-BELT

B7M176411000 B7M176411000

Not available

SHEAVE, PRIMARY FI

59C176110000 59C176110000

149,02 $

Unit Price

SPACER

59C176490100 59C176490100

Not available

O-RING (30X)

932103061100 932103061100

15,49 $

Unit Price

BEARING

933060071300 933060071300

59,90 $

Unit Price

BEARING COVER PLAT

4XM153830000 4XM153830000

15,04 $

Unit Price

SCREW, COUNTERSUNK

901510602300 901510602300

0,94 $

Unit Price

NUT

901792001300 901792001300

23,30 $

Unit Price

SECONDARY FIXED SH

59C176600000 59C176600000

663,69 $

Unit Price

SECONDARY SLIDING

59C176700000 59C176700000

423,76 $

Unit Price

OIL SEAL

931044111900 931044111900

21,13 $

Unit Price

O-RING

932104454500 932104454500

15,36 $

Unit Price

GUIDE PIN

4CW176640000 4CW176640000

1,93 $

Unit Price

SPRING, COMPRESSION

90501620A100 90501620A100

Not available

SPRING SEAT COMP.

5GJ176900000 5GJ176900000

41,42 $

Unit Price

SPRING SEAT

4WV176440000 4WV176440000

30,26 $

Unit Price

NUT

901703627900 901703627900

15,23 $

Unit Price

NUT, HEXAGON (2H7)

901701822100 901701822100

12,60 $

Unit Price

SHAFT, SECONDARY

B7M176810000 B7M176810000

Not available

COLLAR

903872600100 903872600100

41,79 $

Unit Price

O-RING

932102600100 932102600100

9,61 $

Unit Price

OIL SEAL

931024200400 931024200400

31,76 $

Unit Price

BEARING

933062065100 933062065100

76,98 $

Unit Price

BEARING COVER PLAT

5GJ153830000 5GJ153830000

14,40 $

Unit Price

90110-06037-00 *

901100603600 901100603600

2,54 $

Unit Price

CIRCLIP (5U8)

990094250000 990094250000

4,09 $

Unit Price

OIL SEAL

931021500400 931021500400

11,61 $

Unit Price

93306-30218-00 *

933063021700 933063021700

23,68 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
