WATER PUMP

RADIATOR / HOSES FOR YAMAHA TMAX 2022

OIL PUMP

Item numbers

HOSE CLAMP ASSY

904503201500 904503201500

19,08 $

Unit Price

THERMOSTAT ASSY

1WS124100100 1WS124100100

36,41 $

Unit Price

COVER, THERMOSTAT

B7M124130000 B7M124130000

Not available

BOLT, FLANGE DEEP

95E320602000 95E320602000

0,54 $

Unit Price

PIPE 3

B7M124830000 B7M124830000

Not available

RADIATOR COMP

BBW124610000 BBW124610000

Not available

DRAIN COCK

5VU124780000 5VU124780000

8,40 $

Unit Price

BLOWER ASSY

BC3124050000 BC3124050000

Not available

BLOWER HOLDING BOL

2S3126750000 2S3126750000

3,00 $

Unit Price

NUT 1

5SL126710000 5SL126710000

9,48 $

Unit Price

GROMMET

904801630100 904801630100

2,98 $

Unit Price

COLLAR (51L)

90387065L700 90387065L700

8,34 $

Unit Price

COLLAR

903870606500 903870606500

12,77 $

Unit Price

WASHER, PLATE

902010603300 902010603300

0,62 $

Unit Price

GROMMET

904801536300 904801536300

8,72 $

Unit Price

PIPE 6

BC3124760000 BC3124760000

Not available

PIPE 7

BBW124770000 BBW124770000

Not available

CLAMP

904642817500 904642817500

6,32 $

Unit Price

RADIATOR CAP

5SL124620000 5SL124620000

33,48 $

Unit Price

FILLER NECK SUPPOR

5GJ125910000 5GJ125910000

80,58 $

Unit Price

RIVET

902690701400 902690701400

1,50 $

Unit Price

HOSE 1

B7M1243A0000 B7M1243A0000

Not available

HOSE 2

B7M1243E0000 B7M1243E0000

Not available

CLIP

904671500100 904671500100

3,44 $

Unit Price

CLIP

904671003800 904671003800

6,52 $

Unit Price

HOSE 6

BC3125890000 BC3125890000

Not available

HOSE 7

BBW125510000 BBW125510000

Not available

CLAMP

904642300100 904642300100

5,88 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the RADIATOR / HOSES of your Yamaha TMAX 560 of 2022. Let us know if you have any questions.
