STARTER CLUTCH

STARTER CLUTCH FOR YAMAHA VIRAGO 1994

TRANSMISSION

Item numbers

GEAR, PRIMARY DRIVE

22U161110100 22U161110100

Not available

WOODRUFF KEY

902800703600 902800703600

3,62 $

Unit Price

WASHER, CLAW

902141602600 902141602600

10,34 $

Unit Price

WASHER, LOCK (30X)

902151622200 902151622200

4,93 $

Unit Price

90170-16343-00 *

901701631100 901701631100

8,86 $

Unit Price

PRIMARY DRIVEN GEAR COMP.

22U161500100 22U161500100

Not available

THRUST PLATE

22U161540000 22U161540000

11,26 $

Unit Price

BOSS, CLUTCH

22U163710000 22U163710000

Not available

SEAT PLATE

4X7163840000 4X7163840000

22,89 $

Unit Price

CLUTCH BOSS SPRING

4X7163830100 4X7163830100

69,69 $

Unit Price

4X7-16324-10-00 *

4X7163240000 4X7163240000

20,72 $

Unit Price

CLUTCH BOSS RING

4X7163850000 4X7163850000

10,80 $

Unit Price

FRICTION PLATE

22U163210000 22U163210000

26,65 $

Unit Price

4X7-16325-10-00 *

4X7163250000 4X7163250000

23,79 $

Unit Price

PRESSURE PLATE 1

22U163510000 22U163510000

43,84 $

Unit Price

SPRING, COMPRESSIO

905012373800 905012373800

12,50 $

Unit Price

SCREW & WASHER 1W4

901590601600 901590601600

3,87 $

Unit Price

1W1-16358-01-00 *

30X163580000 30X163580000

13,19 $

Unit Price

ROD, PUSH 1

5Y1163560000 5Y1163560000

Not available

O-RING

932100952500 932100952500

7,40 $

Unit Price

92990-06200-00 *

929010620000 929010620000

1,61 $

Unit Price

NUT (661)

953800660000 953800660000

2,05 $

Unit Price

WASHER, LOCK(47X)

902152224400 902152224400

12,41 $

Unit Price

NUT

901702032300 901702032300

11,82 $

Unit Price

BEARING, ROLLER 12

933152181300 933152181300

26,90 $

Unit Price

OIL SEAL

931021827800 931021827800

14,15 $

Unit Price

PUSH LEVER ASSY

22U163800000 22U163800000

59,33 $

Unit Price

TORSION SPRING

905081657700 905081657700

3,59 $

Unit Price

WASHER, PLATE 1682

902011826200 902011826200

5,07 $

Unit Price

WASHER, PLATE

902010808700 902010808700

5,62 $

Unit Price

SCREW

901490806700 901490806700

4,53 $

Unit Price

PUSH ROD 2

22U163570000 22U163570000

38,63 $

Unit Price

BALL (1M1)

935153202900 935153202900

4,06 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the STARTER CLUTCH of your Yamaha XV535S of 1994. Let us know if you have any questions.
