FUEL TANK

SEAT FOR YAMAHA TMAX 2012

SEAT 2

Item numbers

DOUBLE SEAT ASSY

59C247300000

59C247300100

992,05 $

Unit Price

COVER, SEAT

59C247310000 59C247310000

303,97 $

Unit Price

BRACKET, SEAT

4B5247182000 4B5247182000

20,29 $

Unit Price

BRACKET, SEAT

4B5247282000 4B5247282000

20,29 $

Unit Price

DAMPER, SEAT

5SL247230000 5SL247230000

2,50 $

Unit Price

NUT, U FLANGE

956070620000

956040620000

4,30 $

Unit Price

WASHER (23T)

90201065G800 90201065G800

5,56 $

Unit Price

PLATE

4B5247520000 4B5247520000

51,60 $

Unit Price

BOLT, FLANGE

958020602500

Not available

SEAT BACK ASSY

59C247900000

59C247900100

146,61 $

Unit Price

COVER, SEAT BACK

59C247910000 59C247910000

104,74 $

Unit Price

HINGE, SEAT

4B5247260100 4B5247260100

327,25 $

Unit Price

ARM

4B52474E0000 4B52474E0000

10,54 $

Unit Price

NUT, U FLANGE

956020620000

956040620000

4,30 $

Unit Price

CLIP (7U6)

904681812100 904681812100

2,97 $

Unit Price

HINGE, SEAT

4B5247690000

4B5247690100

50,61 $

Unit Price

HINGE, SEAT 2

4B5247790000

4B5247790100

37,68 $

Unit Price

BOLT, BUTTON HEAD

920120802000 920120802000

2,42 $

Unit Price

BRACKET, TAIL COVER

59C2475U0000 59C2475U0000

29,40 $

Unit Price

BOLT, BUTTON HEAD

920120802000 920120802000

2,42 $

Unit Price

DAMPER

59P217460000 59P217460000

9,07 $

Unit Price

BUTTE

4B52478G0200 4B52478G0200

Not available

CLIP

904681600100 904681600100

0,65 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
