BRAKE FOR YAMAHA VMAX 1997

CONTROL CABLE

Item numbers

DISC BRAKE ASSY

8CR2581T0000 8CR2581T0000

Not available

KEY, SLIDING (88K)

902810700400 902810700400

13,75 $

Unit Price

CIRCLIP (8CJ)

934102708000 934102708000

1,95 $

Unit Price

WASHER, PLATE

90201270U500 90201270U500

Not available

CALIPER ASSY (LEFT)

8CR2580T0000 8CR2580T0000

Not available

CALIPER PISTON ASS

8CRW00570000 8CRW00570000

128,67 $

Unit Price

CALIPER SEAL KIT

8CRW00470000 8CRW00470000

25,23 $

Unit Price

8DF-W0046-00-00 *

8CRW00460000 8CRW00460000

77,72 $

Unit Price

PAD SUPPORT

8CR259190000 8CR259190000

28,01 $

Unit Price

PAD PIN

8CR259240000 8CR259240000

17,20 $

Unit Price

BOLT

8CR259260000 8CR259260000

7,70 $

Unit Price

BLEED SCREW KIT

8CRW00480000 8CRW00480000

15,29 $

Unit Price

FLANGE BOLT

901051063800 901051063800

9,96 $

Unit Price

MASTER CYLINDER SUB ASSY

8CRW25870000 8CRW25870000

Not available

MASTER CYLINDER KI

8CRW00410000 8CRW00410000

69,23 $

Unit Price

RESERVOIR CAP SET

8CRW25850000 8CRW25850000

43,27 $

Unit Price

DIAPHRAGM, RESERVO

55U258540000 55U258540000

13,73 $

Unit Price

FLAT HEAD SCREW

987070401200 987070401200

1,87 $

Unit Price

LEVER BOLT

8CR2589F0000 8CR2589F0000

9,98 $

Unit Price

LEVER, LEFT

8CR839120000 8CR839120000

49,53 $

Unit Price

8CR-82530-01-00 *

8CR825300000 8CR825300000

48,26 $

Unit Price

PLAIN WASHER

8CR8398X0000 8CR8398X0000

0,22 $

Unit Price

NUT, FLANGE (4GB)

957070530000 957070530000

2,40 $

Unit Price

BRACKET, MASTER CYLINDER

8CR258670000 8CR258670000

Not available

BOLT (4FL)

913170602000 913170602000

3,84 $

Unit Price

BEAM SWITCH ASSY

8K4839500100 8K4839500100

40,92 $

Unit Price

SCREW

8CR2589H0000 8CR2589H0000

Not available

HOSE, BRAKE 1

8CR258720000 8CR258720000

Not available

UNION BOLT (3GM)

904011015900 904011015900

11,11 $

Unit Price

WASHER, PLATE 481

902011011800 902011011800

6,14 $

Unit Price

JOINT

3LC258850000 3LC258850000

49,34 $

Unit Price

CALIPER BODY COMP. 1

8CR257300000 8CR257300000

Not available

CALIPER BODY COMP. 2

8CR257400000 8CR257400000

Not available

BOLT, WASHER BASED

901050809400 901050809400

Not available

NUT, FLANGE (JN5)

957070850000 957070850000

1,67 $

Unit Price

NUT, HEXAGON SMALL

953170870000 953170870000

1,69 $

Unit Price

COLLAR (82M)

90387084R500 90387084R500

8,84 $

Unit Price

TORSION SPRING

90508291B200 90508291B200

7,41 $

Unit Price

SPRING, TORSION

90508291B100 90508291B100

Not available

PIN (2)

902490600900 902490600900

14,25 $

Unit Price

902490601200 902490601200

14,25 $

Unit Price

COTTER PIN

914902001500 914902001500

3,44 $

Unit Price

97017-06025-00 *

901010628800 901010628800

2,32 $

Unit Price

NUT (JN5)

953170670000 953170670000

2,01 $

Unit Price

8CR-26351-01-00 *

8CR263510000 8CR263510000

74,61 $

Unit Price

LEVER, RIGHT

8CR839220000 8CR839220000

56,61 $

Unit Price

90387-06043-00 *

90387066M300 90387066M300

1,87 $

Unit Price

BUTTON HEAD BOLT

920170601400 920170601400

3,84 $

Unit Price

WASHER, PLATE 6E3

9020106M0800 9020106M0800

4,06 $

Unit Price

COLLAR (7Y6)

90387081M900 90387081M900

6,20 $

Unit Price

BUTTON HEAD BOLT

920170802000 920170802000

5,28 $

Unit Price

WASHER, PLATE 1411

902010808500 902010808500

5,45 $

Unit Price

TAG, CAUTION

8CR234960000 8CR234960000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the BRAKE of your Yamaha VMAX 500 XT of 1997. Let us know if you have any questions.
