FUEL TANK

SEAT FOR YAMAHA TMAX 2015

SEAT 2

DOUBLE SEAT ASSY

2PW247300000

Not available

SEAT COVER

4B5247310000

Not available

BRACKET, SEAT

2PW247380000 2PW247380000

15,92 $

Unit Price

BRACKET, SEAT

2PW247480000 2PW247480000

15,92 $

Unit Price

DAMPER, SEAT

2PW247230000 2PW247230000

3,51 $

Unit Price

NUT, U FLANGE

956070620000

956040620000

4,30 $

Unit Price

WASHER (23T)

90201065G800 90201065G800

5,56 $

Unit Price

PLATE

4B5247520000 4B5247520000

51,60 $

Unit Price

BOLT, FLANGE

958020602500

Not available

SEAT BACK ASSY

4B5247900300

Not available

COVER, SEAT BACK

4B5247910000 4B5247910000

116,90 $

Unit Price

HINGE, SEAT

2PW247260000 2PW247260000

143,33 $

Unit Price

PIN, SEAT FITTING

2PW247270000 2PW247270000

20,53 $

Unit Price

CIRCLIP (4V2)

934300903800 934300903800

2,78 $

Unit Price

ARM

4B52474E0000 4B52474E0000

10,54 $

Unit Price

NUT, SELF-LOCKING

956020820000 956020820000

7,54 $

Unit Price

NUT, U FLANGE

956020620000

956040620000

4,30 $

Unit Price

BRACKET, SEAT

2PW247180000 2PW247180000

14,65 $

Unit Price

BOLT, BUTTON HEAD

920120601000 920120601000

1,68 $

Unit Price

HINGE, SEAT

4B5247690100 4B5247690100

50,61 $

Unit Price

HINGE, SEAT 2

4B5247790100 4B5247790100

37,68 $

Unit Price

BOLT, FLANGE

950220802000 950220802000

1,86 $

Unit Price

BRACKET, TAIL COVER

59C2475U0000 59C2475U0000

29,40 $

Unit Price

BOLT, FLANGE

950220802000 950220802000

1,86 $

Unit Price

DAMPER

59P217460000 59P217460000

9,07 $

Unit Price

BUTTE

4B52478G0200 4B52478G0200

Not available

CLIP

904681600100 904681600100

0,65 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the SEAT of your Yamaha XP500 of 2015. Let us know if you have any questions.
