SEAT

SEAT 2 FOR YAMAHA TMAX 2011

FRONT WHEEL

Item numbers

BOX 1

4B52473R0100

4B52473R0300

313,37 $

Unit Price

DAMPER, SEAT

4B5247370000 4B5247370000

15,01 $

Unit Price

LIGHT, ACCESSORY

4HC847700000 4HC847700000

41,84 $

Unit Price

BULB (12V-2W)

4HC843470000 4HC843470000

8,89 $

Unit Price

SEAL, BOX 2

5GJ2839M0000 5GJ2839M0000

2,50 $

Unit Price

SEAL 3

4B52173M0000

Not available

NUT, SPRING(1YT)

901830504200 901830504200

1,46 $

Unit Price

WIRE, SUB LEAD

4B5825830000 4B5825830000

21,23 $

Unit Price

SEAL 1

1D6223580000 1D6223580000

21,23 $

Unit Price

BOLT, FLANGE

958220602000

958170602000

3,91 $

Unit Price

COLLAR

903870617000 903870617000

4,36 $

Unit Price

CAP

4B52482H0000 4B52482H0000

16,68 $

Unit Price

BOLT, FLANGE

950220601400 950220601400

1,04 $

Unit Price

DAMPER, SEAT

4B5247470000

59C247470100

93,70 $

Unit Price

PASSENGER GRIP

4B52474A01P3

Not available

COLLAR

903870806800 903870806800

10,83 $

Unit Price

BOLT, BUTTON HEAD

920120803500 920120803500

2,62 $

Unit Price

PROTECTOR, 1

4B52476U0000 4B52476U0000

11,32 $

Unit Price

ASSIST, GRIP 2

4B52474W01P3

Not available

COLLAR

903870806800 903870806800

10,83 $

Unit Price

BOLT, BUTTON HEAD

920120803500 920120803500

2,62 $

Unit Price

PROTECTOR, 1

4B52476U0000 4B52476U0000

11,32 $

Unit Price

SEAT LOCK ASSY

4B5247802000 4B5247802000

219,43 $

Unit Price

BOLT, FLANGE

958220601600

958170601600

3,30 $

Unit Price

COLLAR

903870617000 903870617000

4,36 $

Unit Price

SEAT LOCK CABLE ASSY

4B52478D0000 4B52478D0000

103,55 $

Unit Price

BOLT, BUTTON HEAD

920120501000 920120501000

1,53 $

Unit Price

BOLT, HEXAGON

970020501000

970130501000

1,04 $

Unit Price

WASHER(1RW)

929020560000

929070560000

2,13 $

Unit Price

CLAMP

904640700200 904640700200

3,95 $

Unit Price

BRACKET 3

4B52475K0000 4B52475K0000

16,68 $

Unit Price

COVER, REAR FENDER 1

4B52163A0000 4B52163A0000

37,09 $

Unit Price

DAMPER 2

2TV216390000 2TV216390000

1,68 $

Unit Price

RIVET

902690608100 902690608100

3,65 $

Unit Price

NUT, CROWN

901760601700 901760601700

1,87 $

Unit Price

COLLAR

905600806600

903870807900

4,70 $

Unit Price

HANGER, HELMET

4B5213981000 4B5213981000

48,31 $

Unit Price

LABEL, TIRE

5VU216680000 5VU216680000

6,49 $

Unit Price

TOOL KIT

4B5281001000 4B5281001000

92,39 $

Unit Price

BAND, BATTERY

3TJ821310000 3TJ821310000

14,12 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the SEAT 2 of your Yamaha XP500 of 2011. Let us know if you have any questions.
