SEAT

SEAT 2 FOR YAMAHA TMAX 2003

FRONT WHEEL

BOITE 1

5GJ2473R0000 5GJ2473R0000

Not available

AMORTISSEUR, REPOSE-PIEDS

5GJ274140000 5GJ274140000

Not available

PLAQUE 1

5GJ274450000 5GJ274450000

Not available

NUT, SPRING

901830507600

90183050A600

4,94 $

Unit Price

BOLT

901110500200 901110500200

2,54 $

Unit Price

DAMPER, SEAT

5GJ247230000 5GJ247230000

1,49 $

Unit Price

SILENT-BLOC DE SELLE

5GJ247370000 5GJ247370000

Not available

LIGHT, ACCESSORY

4HC847700000 4HC847700000

41,84 $

Unit Price

BULB (12V-2W)

4HC843470000 4HC843470000

8,89 $

Unit Price

SEAL, BOX 2

5GJ2839M0000 5GJ2839M0000

2,50 $

Unit Price

BOLT(3KJ)

90109063F100 90109063F100

4,46 $

Unit Price

SILENT-BLOC DE SELLE

5GJ247470000 5GJ247470000

Not available

POIGNEE, SELLE

5GJ2477300P0 5GJ2477300P0

Not available

WASHER, PLATE 2562171800

902010808800 902010808800

4,16 $

Unit Price

BOLT, BUTTON

920170803000 920170803000

2,46 $

Unit Price

PROTECTEUR2

5GJ2476V0000 5GJ2476V0000

Not available

PROTECTEUR

5GJ2476U0000 5GJ2476U0000

Not available

ANTIVOL DE SELLE

5GM247800100 5GM247800100

Not available

BOLT

901090603600 901090603600

2,55 $

Unit Price

BOLT, FLANGE

958070601600

958170601600

3,30 $

Unit Price

CABLE, CROCHET DE SIEGE

5GJ2478E0000 5GJ2478E0000

Not available

WIRE

5GJ2473W1000 5GJ2473W1000

Not available

WIRE

5GJ2473W0000 5GJ2473W0000

Not available

CONNECTEUR, CABLE

2T5262610200 2T5262610200

Not available

BOUCHON DE CONNECTEUR DE CABLE

2T5262620000 2T5262620000

Not available

GUIDE, ROTOR

2T5262740000 2T5262740000

5,17 $

Unit Price

ROTOR

2T5262730000 2T5262730000

3,72 $

Unit Price

SLIDER

2T5262440000 2T5262440000

5,92 $

Unit Price

2T5262670000 2T5262670000

3,08 $

Unit Price

SPRING, COMPRESSION (2T5)

905010551200 905010551200

2,63 $

Unit Price

SCREW, TAPPING (3J0)

901670300400 901670300400

2,61 $

Unit Price

CAP, RUBBER

304263290000 304263290000

2,07 $

Unit Price

BOUCHON, CAOUTCHOUC

58E263290000 58E263290000

Not available

HOLDER

3J0263930000 3J0263930000

5,61 $

Unit Price

PROTECTEUR

5GJ263670000 5GJ263670000

Not available

NUT, HEXAGON

953070560000

953170560000

1,90 $

Unit Price

BOLT

970070501000

970270501000

2,14 $

Unit Price

PASTILLE DE SELLE

5GJ247410000 5GJ247410000

Not available

HANGER, HELMET

4HC213980000 4HC213980000

53,28 $

Unit Price

PROTECTOR

5GJ2639E0000 5GJ2639E0000

Not available

SCREW, WITH WASHER (517).

901590601300 901590601300

2,14 $

Unit Price

AMORTISSEUR

5GJ248540000 5GJ248540000

Not available

TROUSSE A OUTILS

5GJ281000000 5GJ281000000

Not available

BAND, TOOL

4XV213760000 4XV213760000

13,44 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
