STARTER CLUTCH

STARTER CLUTCH FOR YAMAHA VIRAGO 1996

TRANSMISSION

PRIMARY DRIVE GEAR

22U161110100

4KU161110000

82,13 $

Unit Price

KEY, WOODRUFF (22U)

902800703600 902800703600

3,77 $

Unit Price

WASHER, CLAW (11H)

902141602600 902141602600

10,78 $

Unit Price

WASHER, LOCK (30X)

902151622200 902151622200

5,14 $

Unit Price

NUT(24V)

901701631100

901701634300

9,24 $

Unit Price

PRIMARY DRIVEN GEAR COMP.

22U161500100 22U161500100

374,56 $

Unit Price

PLATE, THRUST 1

22U161540000 22U161540000

11,74 $

Unit Price

CLUTCH BOSS

22U163710000

22U163710200

111,70 $

Unit Price

PLATE, SEAT

4X7163840000 4X7163840000

23,86 $

Unit Price

SPRING, CLUTCH BOSS

4X7163830100 4X7163830100

72,65 $

Unit Price

PLATE, CLUTCH 1

4X7163240000

4X7163241000

21,60 $

Unit Price

RING, CLUTCH BOSS

4X7163850000 4X7163850000

11,26 $

Unit Price

PLATE, FRICTION

22U163210000 22U163210000

27,78 $

Unit Price

PLATE, CLUTCH 2

4X7163250000

4X7163251000

24,80 $

Unit Price

PLATE, PRESSURE 1

22U163510000 22U163510000

45,70 $

Unit Price

SPRING, COMPRESSION (22U)

905012373800 905012373800

13,03 $

Unit Price

SCREW, WITH WASHER (1W4)

901590601600 901590601600

4,03 $

Unit Price

PLATE, PUSH

1W1163580100 1W1163580100

13,75 $

Unit Price

TIGE DE DEBRAYAGE

6Y1163560000 6Y1163560000

Not available

O-RING (5Y1)

932100952500 932100952500

7,71 $

Unit Price

WASHER(6TA)

929070620000 929070620000

2,13 $

Unit Price

NUT(6TA)

953070660000

953170660000

2,10 $

Unit Price

WASHER, LOCK(47X)

902152224400 902152224400

12,94 $

Unit Price

NUT (26H)

901702032300 901702032300

12,32 $

Unit Price

BRG, CYL-CAL ROLLER 12G KY

933152181300 933152181300

28,04 $

Unit Price

OIL SEAL (22U)

931021827800 931021827800

14,75 $

Unit Price

PUSH LEVER ASSY

22U163800000 22U163800000

61,85 $

Unit Price

SPRING, TORSION (22U)

905081657700 905081657700

3,74 $

Unit Price

WASHER PLATE 168217580000

902011826200 902011826200

5,29 $

Unit Price

WASHER, PLATE 3411117500

902010808700 902010808700

5,86 $

Unit Price

SCREW 425163430000

901490806700 901490806700

4,72 $

Unit Price

ROD, PUSH 2

22U163570000 22U163570000

40,27 $

Unit Price

BALL (1M1)

935153202900 935153202900

4,23 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the STARTER CLUTCH of your Yamaha XV500S of 1996. Let us know if you have any questions.
