SWINGARM

REAR SHOCK ABSORBER FOR YAMAHA XTZ 1987

STEERING

AMORTISSEUR, ARRIERE

55W222100026 55W222100026

Not available

AMORTISSEUR, ARRIERE

55W22210006W 55W22210006W

Not available

.SOUS-AMORTISSEUR SOUS-AMORTISSEUR

55W224010000 55W224010000

Not available

.COUVERCLE COUVERCLE

3R4222210100 3R4222210100

Not available

.TAMPON, BUTEE TAMPON, BUTEE

50T224930000 50T224930000

Not available

.SUPPORT SUPERIEUR SUPPORT SUPERIEUR

50T224090000 50T224090000

Not available

34L-22226-01-00 *

34L222260000 34L222260000

Not available

BUSH, SOLID

903801413000 903801413000

8,42 $

Unit Price

.GOUJON GOUJON

936042613200 936042613200

Not available

ECROU, REGLAGE

50T224970000 50T224970000

Not available

.COUVERCLE COUVERCLE

50T222110000 50T222110000

Not available

.BAGUE, COUVERCLE BAGUE, COUVERCLE

50T222150000 50T222150000

Not available

.SIEGE, SUPERIEUR DE RESSORT SIEGE, SUPERIEUR DE RESSORT

50T222130000 50T222130000

Not available

.RESSORT RESSORT

55W222120026 55W222120026

Not available

.RESSORT RESSORT

55W22212006W 55W22212006W

Not available

.GUIDE, RESSORT 2 GUIDE, RESSORT 2

50T222240000 50T222240000

Not available

.SIEGE INFERIEUR, RESSORT SIEGE INFERIEUR, RESSORT

3Y1222230000 3Y1222230000

Not available

.CIRCLIP, TYPE S CIRCLIP, TYPE S

934404807900 934404807900

Not available

.GOUJON GOUJON

936042119300 936042119300

Not available

DOWEL PIN

936021114400 936021114400

0,82 $

Unit Price

BOLT

901011249800 901011249800

10,36 $

Unit Price

WASHER, PLATE 2781

902011236200 902011236200

4,89 $

Unit Price

90185-12134-00 *

901851208000 901851208000

10,88 $

Unit Price

COUVERCLE, BUTEE 2

34L221290000 34L221290000

Not available

PIN, CLEVIS (34L)

902401410600 902401410600

14,50 $

Unit Price

92990-14600-00 *

929011460000 929011460000

12,57 $

Unit Price

COTTER PIN

914013002500 914013002500

5,53 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the REAR SHOCK ABSORBER of your Yamaha XT500Z of 1987. Let us know if you have any questions.
