HEADLIGHT FOR YAMAHA XTZ 1987

TAIL LIGHT

PHARE

43F84303G000 43F84303G000

Not available

HEADLIGHT RIM

47J841150000 47J841150000

86,73 $

Unit Price

.OPTIQUE COMPLET OPTIQUE COMPLET

34L84321G000 34L84321G000

Not available

BULB FITTING PLATE

2F9843750000 2F9843750000

12,74 $

Unit Price

COVER, SEAT

2F9843970100 2F9843970100

22,27 $

Unit Price

.DOUILLE, LAMPE-TEMOIN DOUILLE, LAMPE-TEMOIN

34L843460000 34L843460000

Not available

SCREW, RIM ADJUSTE

43F841310000 43F841310000

5,33 $

Unit Price

.RONDELLE, SPECIALE RONDELLE, SPECIALE

233841270000 233841270000

Not available

SPRING, ADJUST

341843326000 341843326000

9,12 $

Unit Price

NUT, ADJUSTING

198843346000 198843346000

8,19 $

Unit Price

SET SPRING

14T841240000 14T841240000

4,61 $

Unit Price

COVER

10V841960000 10V841960000

16,64 $

Unit Price

COVER FITTING CLIP

10V841980000 10V841980000

7,14 $

Unit Price

97007-06020-00 *

970110602000 970110602000

2,32 $

Unit Price

90387-06158-00 *

903870638800 903870638800

2,84 $

Unit Price

GROMMET 8397743100

904801402300 904801402300

6,14 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the HEADLIGHT of your Yamaha XT500Z of 1987. Let us know if you have any questions.
