SIDE COVER

SWINGARM FOR YAMAHA SR 1987

STEERING

BRAS ARRIERE COMP.

3H0221100133 3H0221100133

Not available

BAGUE

33Y221240000 33Y221240000

Not available

BEARING, ROLLER 28

933172220800 933172220800

42,16 $

Unit Price

BEARING, ROLLER 30

933422220500 933422220500

73,31 $

Unit Price

90201-22284-00 *

648455330003 648455330003

0,51 $

Unit Price

THRUST COVER

2K8221290000 2K8221290000

19,96 $

Unit Price

GUARD SEAL

431221510300 431221510300

20,15 $

Unit Price

OIL SEAL 35X41.5X8

931083500400 931083500400

16,94 $

Unit Price

PIVOT SHAFT

33Y221410100 33Y221410100

76,03 $

Unit Price

NUT (2J2)

901791625600 901791625600

22,55 $

Unit Price

2J2-22311-01-00 *

2J2223110193 2J2223110193

116,81 $

Unit Price

97395-06016-00 *

973130601600 973130601600

1,88 $

Unit Price

92995-06100-00 *

929900610000 929900610000

1,40 $

Unit Price

97001-06020-00 *

973010602000 973010602000

2,32 $

Unit Price

90480-13398-00 *

904801319700 904801319700

4,34 $

Unit Price

90387-060A3-00 *

903870621600 903870621600

2,96 $

Unit Price

WASHER, PLATE 1012

902010606600 902010606600

4,49 $

Unit Price

95024-06010-00 *

950230601000 950230601000

2,31 $

Unit Price

AMORTISSEUR, ARRIERE

48U222100093 48U222100093

Not available

WASHER, PLATE 1482

902011421500 902011421500

5,63 $

Unit Price

WASHER

902011069600 902011069600

4,14 $

Unit Price

WASHER

902011069600 902011069600

4,14 $

Unit Price

NUT, CAP (371)

901761000900 901761000900

4,86 $

Unit Price

90176-10073-00 *

901761001300 901761001300

10,05 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the SWINGARM of your Yamaha SR500 of 1987. Let us know if you have any questions.
