FRAME

FENDER FOR YAMAHA SR 1987

SIDE COVER

GARDE BOUE AV

48U215100193 48U215100193

Not available

BOLT

973130802000 973130802000

2,88 $

Unit Price

YBS67-8 WASHER, SPRING

929900810000 929900810000

1,68 $

Unit Price

HOLDER, WIRE

1A0215180000 1A0215180000

4,92 $

Unit Price

GARDE BOUE AR

2J4216101093 2J4216101093

Not available

DAMPER, REAR

168216390000 168216390000

12,58 $

Unit Price

COLLAR (437)

903870825800 903870825800

12,96 $

Unit Price

BOLT

973010803500

970130803500

5,65 $

Unit Price

NUT(6L2)

953030860000

953330860000

3,75 $

Unit Price

YBS67-8 WASHER, SPRING

929900810000 929900810000

1,68 $

Unit Price

WASHER, PLATE (5J0)

90201085E600 90201085E600

3,96 $

Unit Price

GUARD, MUD

2J2216290100 2J2216290100

41,71 $

Unit Price

WASHER, PLATE

902010606700

902010638000

5,48 $

Unit Price

BOLT, HEXAGON DEEP RECESS

973130601600

97D950601600

1,96 $

Unit Price

WASHER(6A1)

929900610000

929950610000

1,46 $

Unit Price

CLAMP (1A0)

904640802000 904640802000

9,22 $

Unit Price

SUPPORT, ARRIERE

48U216450000 48U216450000

Not available

BOLT, FLANGE (3JPE)

950230801600

950240801600

3,62 $

Unit Price

GROMMET, SEAT HANDLE

1J3247420000 1J3247420000

5,22 $

Unit Price

BAVETTE

2J4216211000 2J4216211000

Not available

BOLT, HEXAGON DEEP RECESS

973130601600

97D950601600

1,96 $

Unit Price

COLLAR

903870602200

903870610600

3,05 $

Unit Price

NUT(661)

953030660000

953800660000

2,14 $

Unit Price

WASHER, PLATE (J10)

902010607000

902010669700

4,00 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FENDER of your Yamaha SR500 of 1987. Let us know if you have any questions.
