LEG SHIELD FOR YAMAHA OVETTO 2002

COVER 1

Item numbers

PROTEGE-JAMBES 1

5ADF8311014B 5ADF8311014B

Not available

PROTEGE-JAMBES 1

5ADF831101PK 5ADF831101PK

Not available

PROTEGE-JAMBES 2

5ADF83120000 5ADF83120000

Not available

PROTEGE-JAMBES 2

5ADF83121000 5ADF83121000

Not available

VIS, TETE FRAISEE

9770M5001600 9770M5001600

Not available

NUT, SPRING(1YT)

901830504200 901830504200

1,40 $

Unit Price

CROCHET

5ADF83791000 5ADF83791000

Not available

CROCHET

5ADF83790000 5ADF83790000

VIS, AVEC RONDELLE

901590681600 901590681600

Not available

COUVERCLE

5KKF83851000 5KKF83851000

Not available

COUVERCLE

5KKF83852000 5KKF83852000

Not available

VIS, TETE FRAISEE

9770M5001600 9770M5001600

Not available

EMBLEME

5RNF8315A000 5RNF8315A000

Not available

EMBLEME

5NRF8368A000 5NRF8368A000

Not available

MOULURE, GARDE BOUE

5ADF1519014B 5ADF1519014B

Not available

MOULURE, GARDE BOUE

5ADF151901PH 5ADF151901PH

Not available

MOULURE, GARDE BOUE

5ADF151901PK 5ADF151901PK

Not available

VIS, TETE FRAISEE

9770M5001600 9770M5001600

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the LEG SHIELD of your Yamaha YN50 of 2002. Let us know if you have any questions.
